12
ROTEX
GB
Original operating manual
The specified illustrations appear at the be-
ginning of the Operating Instructions.
1Symbols
2 Technical data
3 Machine features
* not on all versions included in the scope of
delivery
4 Intended use
As specified, the machines is designed for
sanding and polishing plastic, metal, wood,
composite materials, paint/clear coats, filler
and similar materials. Materials containing
asbestos must not be processed.
To guarantee electrical safety, the machine
must not be damp or operated in a damp en-
vironment. The machine must only be used
for dry sanding.
The user bears the responsibility for
damage and accidents caused by im-
proper use.
5 Safety instructions
5.1 General safety instructions
WARNING! Read all safety warnings
and all instructions.
Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
5.2 Machine-related safety instruc-
tions
–
Harmful/toxic dusts can be produced
during your work (e.g. lead-contain-
ing paint, some types of wood and
metal).
Contact with these dusts, espe-
cially inhaling them, can represent a haz-
ard for operating personnel or persons in
the vicinity. Comply with the safety regula-
1 Symbols .................................. 12
2 Technical data .......................... 12
3 Machine features ...................... 12
4 Intended use............................ 12
5 Safety instructions .................... 12
6 Operation ................................ 13
7 Settings................................... 14
8 Working with the machine.......... 15
9 Service and maintenance ........... 15
10 Accessories .............................. 16
11 Disposal .................................. 16
12 Warranty ................................. 16
13 EU Declaration of Conformity...... 17
Warning of general danger
Risk of electric shock
Read the Operating Instructions/
Notes!
Wear protective goggles.
Wear ear protection.
Wear a dust mask.
Disconnect from the power supply!
Gear-driven eccentric
sander
RO90 DX
FEQ
Power 400 W
Speed
Eccentric motion 3000 - 7000 rpm
Rotex rotary motion 220 - 520 rpm
Sanding stroke 3,0 mm
FastFix sanding pad dia. 90 mm
Weight (without mains
cable, with sanding pad)
1,45 kg
Safety class /II
[1-1] Protector
[1-2] Change-over switch/spindle stop
[1-3] On/Off switch
[1-4] Mains power cable
[1-5] Extractor connector
[1-6] Speed control
[1-7] Sanding pad
[1-8] Stop rod
[1-9] Polishing pad*
[1-10] Delta sanding pad
[1-11] Slat sanding pad*
[1-12] Interface pad*
