![Victoria Arduino Theresia T3 [41/106] General remarks on the consignment](/views2/1996252/page41/bg29.png)
41
EN
1. GENERAL REMARKS ON
THE CONSIGNMENT
1.1 SAFETY REGULATIONS
01. The present manual is an integral and
essential part of the product and will
have to be handed over to the user.
Read carefully the written warnings
in the present manual as they give
important suggestions concerning
the safety of installation and set-
up, use and maintenance. Keep this
manual in a safe place for further
information.
02. All illustrations contained in this
manual are meant for information
purposes only. Your appliance may
dier in some parts compared to the
one shown on the picture. Victoria
Arduino reserves the right to make
changes to production and to the
manual without any obligation to
update previous production and
manuals accordingly.
POLLUTION DANGER
03. Aer removing the packaging, verify
appliance integrity. If in doubt, do
not use the machine and contact the
professionally qualified personnel.
The elements of the packaging must
be kept out of children’s reach as they
can be potential sources of danger
and they mustn’t be disposed of in
the environment.
04. Before connecting the machine,
make sure that the data of the
plate correspond to those of the
electrical distribution network. The
installation has to be carried out in
compliance with the regulations of
the Country where the machine is
set-up, according to the instructions
by the manufacturer and qualified
personnel. The manufacturer can’t be
considered responsible for possible
damage caused by failure in earthing
the plant. For the electrical safety
of this machine it is obligatory to
arrange the earthing plant, contact
an electrician with proper and
certified technical suitability, to
check the electrical capacity of the
plant is adequate to the maximum
power of the machine, stated on the
plate. In particular the electrician will
have to make sure that the section of
the plants’ cables is suitable to the
power absorbed by the machine. Do
not use adapters, multiple socket and
extensions. If their use is necessary,
it is compulsory to call a licensed
electrician.
05. For appliances at 220-230 V, the
highest impendence from the power
mains mustn’t exceed 0,37 ohm.
06. When installing the device, it is
necessary to use the parts and
materials supplied with the device
itself. Should it be necessary to use
other parts, the installation engineer
needs to check their suitability for the
use in contact with water for human
consumption.
07. This machine must be installed
according to the applicable federal,
state, and local standards (codes)
in force with regard to plumbing
systems. For this reason, the plumbing
connections must be carried out by a
qualified technician.
08. The device is to be supplied with water
suitable for human consumption
and compliant with the regulations
in force in the place of installation.
The installation engineer requires
the confirmation from the owner/
manager of the system that the water
complies with the requirements and
standards stated above.
09. This machine will have to be used
