Victoria Arduino Theresia T3 [66/106] Cleaning and maintenance
![Victoria Arduino Theresia T3 [66/106] Cleaning and maintenance](/views2/1996252/page66/bg42.png)
66
EN
9. CLEANING AND
MAINTENANCE
9.1 SWITCHING OFF THE
MACHINE
To switch the machine o, press the main
switch and set the machine to the "O"
position.
9.2 CLEANING THE OUTSIDE
OF THE MACHINE
The machine must be set to “O” power
(switch o and disconnector open) be-
fore any cleaning operations.
WARNING
Do not use solvents, chlorine-based
products or abrasives.
WARNING
It is not possible to clean the machine us-
ing water jets or immersing it in water.
Cleaning the work area: remove the
worktop grid, liing it up from the front
and sliding it out. Remove the water col-
lection dish underneath and clean with
hot water and cleansers.
Cleaning the bottom: To clean all the
chromium-plated areas, use a so, damp
cloth.
9.3 CLEANING THE STAINLESS
STEEL COFFEE-HOLDERS
The stainless steel coee holder is situ-
ated underneath the dispensing unit.
NOTE
To clean proceed as follows:
ȗ Turn the screw placed in the centre of
the coee-holder.
ȗ Slide the coee-holder out and check
that its holes are not obstructed.
ȗ If obstructed, clean as described
(Paragraph “CLEANING FILTERS AND
FILTER-HOLDERS”).
It is recommended to clean the
coee-holder once a week.
9.4 CLEANING THE UNIT WITH
THE AID OF THE BLIND FILTER
The machine is pre-set for cleaning the
delivery unit with a specific washing
powder.
The machine will initiate washing cycle
which consists in the circulation of hot
water followed by regular breaks.
We recommend carrying out a washing
cycle at least once a day with special
cleansers.
RISK OF INTOXICATION
Once the filter-holder has been removed,
repeat delivery operations a few times to
eliminate any cleanser residues.
To carry out the washing procedure,
proceed as follows:
01. Substitute the filter with the delivery
unit blind filter.
02. Fill it with two spoonfuls of special
cleanser powder and insert it into the
unit filter-holder.
03. Press the Hot water
and Steam
keys at the same time, and then press
ENTER
to restart the cleaning.
