Victoria Arduino Theresia T3 [51/106] Turning the machine on
![Victoria Arduino Theresia T3 [51/106] Turning the machine on](/views2/1996252/page51/bg33.png)
51
EN
6. USE
Before starting any operation, the opera-
tor must be sure to have read and under-
stood the safety prescriptions contained
in this booklet.
The model
is
equipped with an User’s visualization key
and a Technician key. The User’s visual-
ization key allows to access the normal
operating functions and to visualize the
programming menus (Chapter 7).
The Technician’s key allows to access all
particular functions and to modify the
parameters.
6.1 TURNING THE MACHINE
ON
ȗ Switch o the disconnector and set
the main switch A to I.
12
ȗ The information about the soware
and the machine status are shown on
the display.
NOTE
The machine is not operative as the main
switch only supplies the electronic card.
WARNING
In case of electronic card maintenance,
turn the machine o by means of the ex-
ternal main switch or unplug it.
6.2 FIRST INSTALLATION
PROCEDURE AND MANUAL
WATER FILLING IN THE
TANK
When commissioning the machine for
the first time or aer carrying mainte-
nance switch ON the machine using the
main switch positioned lower down and
on the right and proceed as follows:
ȗ When starting the machine, the
display shows the soware release:
13
ȗ When starting the machine for the
first time, the display shows as
follows:
14
ȗ Press the ON/OFF
button to start
the machines. The display shows as
follows:
A
