button a second time).
5' Timer function:
Holding the buttons P2, P3, P4 or P5 pressed down
(>2") the 5' Timer function is activated. When the time
has run out, the motor turns off and the lift closes. The
LEDs change from High to Low intensity. When the
function is active, the LED corresponding to the current
motor speed blinks.
Filter alarm display:
Grease filters: After 30h of motor operation, the LED of
the P1 button comes on for 30'' every time the motor
turns off.
Charcoal filter: After 120h of motor operation, the LED of
the P1 button blinks for 30'' every time the motor turns
off.
CONTROLS Fig.26:
P1: Motor on/off - 1st speed
P2: 2nd speed
P3: 3rd speed
P4: 4th speed
P5: Lift panel up/down (during opening the panel can be
stopped at the desired height by pressing the
button a second time).
5' Timer function:
When the motor is on, holding the keys P1-P4 pressed
down (depending on the speed set), the 5' timer function
is activated. When this function is active, the LED
corresponding to the speed (L1-L4) blinks. When the 5'
have elapsed, the motor turns off and the carriage
closes.
Filter alarm display:
After 30 hours of motor operation, the LEDs L1-L5 come
on for 30'' each time the motor is turned off.
After 120 hours of motor operation, the LEDs L1-L5 blink
for 30'' each time the motor is turned off.
To reset the alarm, press any one of the keys P1-P5 for
2" during alarm display.
CONTROLS Fig.27:
A = Stand-by/OFF/Slider
When the chimney cooker hood is on, pressing this button
will open the slider up to 30 cm. (button blinks rapidly). A
second press on of the button will lift the chimney cooker
hood to 40 cm. If the chimney cooker hood has not received
further commands, Stand-by mode will turn on, which will
then automatically turn off after 5 minutes. In Stand-by
mode, buttons A will light, and buttons B,C, and F will only
be backlit.
When the chimney cooker hood is turned on, holding on the
pressed button (> 2") will turn off the device (engine, lights,
and timer, if it is turned on). Pressing the button
while the truck is in motion, the direction is reversed.
Cleanup Mode:
Before cleaning the chimney cooker hood, make sure that
the chimney cooker hood is turned off (only button A should
be backlit). Pressing and holding the button (> 2") will turn
on/off working mode for 3 minutes: during this time the
chimney cooker hood must not receive any commands (all
buttons are only backlit).
B = Lighting level / OFF button. In order to select high,
medium, or low lighting level, or turn the lighting off
completely, the button should be pressed several times.
Holding on the pressed button (> 2") will turn on/off accessary
lighting (only available in certain models).
C = engine ON/OFF button. When the engine is not working,
pressing the button will turn on the first speed mode of the
engine (lighting slider L area). When the engine is working,
pressing this button will turn off the engine.
D = Lower engine speed button
E = Increase engine speed button
L = Slider area for engine speed. Sliding finger on this area
(i.e. pressing and sliding finger) will increase or lower
engine speed. High speed is signaled by red.
F = Timer. In order to turn the Timer on, an appropriate
button should be pressed. Engine will stop automatically
after 5 minutes (button blinks rapidly). Pressing the button
when the 5-minute Timer is on will turn on the 10-minute
Timer (button blinks slowly). In order to turn the Timer off,
press and hold the button (> 2").
G = Anti-grease filter (filters) alert. After 30 hours of
chimney cooker hood work, the necessity to clean anti-
grease filters will be signaled by backliting this button. In
order to reset work time, press and hold the button (> 2").
H = Charcoal filter (filters) alert. After 120 hours of chimney
cooker hood work, the necessity to clean charcoal filters
(installed in chimney cooker hoods with this option) will be
signaled by backliting this button. In order to reset work
time, press and hold the button (> 2").
!
ATTENTION
SAFETY SYSTEMS
In order to function correctly the product is equipped
with a series of safety devices which are also intended
to prevent any injury caused by inappropriate use.
In any case be very careful in using the product, above
all the parts in motion.
ALARM ON CONTROL (Controls Fig. 24-25-26)
1. All LEDs flashing: this means that the telescopic
trolley is locked. Wait 30” and then press the UP/
DOWN button to release the trolley
2. UP/DOWN button LED flashing: this means that the
front panel of the filters is not closed properly.
Reposition it correctly.
ALARM ON CONTROL (Controls Fig. 27)
1. Flashing arrows (buttons D, E): means that the telescopic
carriage is locked.
2. G button blinking: means that the grease filter is not
properly latched. Reposition it properly.
To remove the alarm, press the A button (with a short press
the carriage will continue the race, with long press the trolley
closes).
MAINTENANCE
! Before cleaning or maintenance cut the power.
If the light spot is damaged, it must be replaced only by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard
