Before performing any cleaning or maintenance operations, disconnect the appli-

ance by unplugging it or using the main switch. The manufacturer disclaims all li-

ability for any damage that may be directly or indirectly caused to people, things and

animals due to the failure to follow all the instructions provided in this booklet and

above all the warnings relating to the installation, operation and maintenance of the

appliance.

- there is a fire risk if cleaning is not carried out in accordance with the instructions

CAUTION: Accessible parts may become hot when used with cooking appliances

Warning: Failure to install the screws or fixing device in accordance with these instructions

may result in electrical hazards

CAUTION:

This product must be disposed of at end of life according to the rules in force.

TECHNICAL SPECIFICATIONS

The technical data pertaining to the electric appliance The technical specifications of the ap-

pliance are shown on the rating plates located inside the range hood.

INSTALLATION

(Section reserved for qualified installers of the range hood)

The recommended distance between the cooker and the lower part of the range hood for the

installation is about 110 cm. In borderline cases, with a slight efficiency loss, the distance can be

increased to about 150 cm. The minimum distance cannot be less than 65 cm, as envisioned

by the Standard.

Should the instructions of the gas cooker specify a greater distance, take this into considera-

tion.

In the outside exhaust version, the diameter of the fume discharge duct must be no smaller

than the range hood connection.

In the horizontal sections, the duct must slope slightly (around 10%) upwards, so at to better

convey the air outside of the room.

Reduce curves to the bare minimum, and check that the length of the ducts is also the bare

minimum.

Comply with the current regulations on air discharge into the atmosphere.

If other appliances that use gas or other fuels are being used at the same time (boiler, stove,

fireplaces, etc.), make sure the room where the fumes are extracted is well ventilated, in compli-

ance with the current regulations.

Assembly instructions: see section “O” of the booklet.

ELECTRICAL CONNECTIONS

(Section reserved for qualified installers)

WARNING!

Before doing any work inside the range hood, disconnect the appliance from the

mains power supply.

Check that the wires inside the range hood are not disconnected or cut; if this is the

case, contact your nearest service centre. The electrical connections must be per-

formed by qualified personnel.

The connections must be performed in compliance with the legal standards in force. Check
