INDEX
109
Symbols
+4dB analog input 20
-10dB analog input 20
1394 connector 6, 11, 18, 19
192kHz
operation
30
24-bit
3rd party software
53
recording 12
48V phantom power 41
4-pin FireWire 23
6-pin FireWire 23
828
connecting to UltraLite-mk3
27
896mk3
connecting to UltraLite-mk3
27
A
Ableton Live 45
Activity meters 12
All Notes Off (LCD) 38
Analog inputs/outputs 6
making connections to 20
overview 10
trim 67
Analog meters 12
Application follows control surface 101
ASIO 12, 15, 16, 43
software
clock source
44
Attack
compressor
80
Audio
bit resolution
30
Audio Setup software 29
AudioDesk
MOTU 828mk3 settings
7
AutoSave Status 38
B
Balance 65
Balanced analog 20
Buffer Size 31, 57
Bus
activity LEDs
71, 82
fader 64
Bus power 23
examples 23
requirements 23
C
Channel tab 70
reverb settings 71
Clear Peaks 87
Clock
192kHz operation
30
Clock source 7, 30
SMPTE setting 31
Combo jacks 5, 6
Comp button 82
Compressor 80
enabling 80
Condenser mic input 5, 20
Configurations menu 100
Configure interface 26
Connecting multiple UltraLite-mk3s 26
Control Surfaces menu 101
Controller
connecting
22
Converters 6
Copy/Paste 87
Cubase 12, 29
choosing the UltraLite-mk3 driver
45
clock source 44
Main Out Assign 45
phones 44
Return Assign 46
reverb return 47, 52
sample rate 44
synchronization 47
CueMix
menu
38
CueMix FX 58, 61-102
Application follows control surface
101
Configurations menu 100
control surfaces 102
Control Surfaces menu 101
Cubase/Nuendo 47
CueMix control surfaces 102
Devices menu 88
Edit menu 87
File menu 87
focus 63
installation 62
Listenback explained 85
listenback settings 86
Mixer 35
output jacks 21
overview 61, 63
Phones menu 101
Share surfaces with other applica-
tions
102
shortcuts 87
signal flow 66
SONAR 52
stand-alone operation 62
Talkback menu 101
talkback settings 85, 86
Customer support 108
D
Daisy-chaining 23, 26, 27
DAT
connecting
22, 25
DC power supply 24
Delay (latency) 55
Devices menu 88
Digital Performer
828mk3 settings
7
Direct Monitoring 46
Disable interface option 27, 33
Disable option 27
Disk
getting a replacement
108
Drivers
Legacy MME (Wave)
7
DSP
meter
62, 85
resources 62, 85
Dynamic mic 20
Dynamics
enabling
68, 80
graph 67
inputs 67
outputs 68
tab 80
E
Early reflections 84
Enable full Wave support 32
Enable Pedal 32
EQ
enabling
68, 72
filter types 76
frequency 76
gain 76
graph 67
inputs 67
outputs 68
Q 76
tab 72
Expansion 26
F
Factory defaults 38
Feedback loops 47, 52
File menu
Clear Peaks
87
Copy/Paste 87
Hardware Follows CueMix Stereo
Settings
87
Load Hardware Preset 87
Mix1 return includes computer 87
Peak/Hold Time 87
Save Hardware Preset 87
undo/redo 87
FireWire 11
6-pin vs. 4-pin 23
additional busses 27
connecting 18, 19
connector 6
PC card adapters 23
PCI cards 23
Focus 63
Inputs tab 66
Mixes tab 65
Outputs tab 68
Follow Active Mix 101
Forget button 27, 33
Freewheel
address
104
clock 104
infinite 104, 105
Frequency
EQ
76
