MOTU ULTRALITE MKIII HYBRID [70/112] The channel settings section

CUEMIX FX

THE CHANNEL SETTINGS SECTION

The channel settings section in the CueMix FX

window (Figure 10-1) displays three tabs for

Channel, EQ and Dynamics settings for the

channel with the current focus. There are also two

global tabs: the Meter Bridge and the Reverb

Processor, as shown below.

Figure 10-7: The Channel Settings section.

The Channel tab

The Channel tab (Figure 10-8) displays settings for

input channels. Click any focus button in the

Inputs tab to view the Channel tab settings for the

channel.

Figure 10-8: The Channel tab.

Signal ﬂow

Settings in the Channel tab occur just before the

EQ, dynamics and reverb sends in the Input tab

channel strip (Figure 10-3 on page 66). Input

channel signal ﬂow is as follows: trim, phase, stereo

versus M/S decoding, width, L/R swap, EQ,

dynamics and reverb send.

Pad and phantom

The Pad and phantom settings become active

(ungrayed) when the focus is on a mic input (or

both mic inputs). These are the same 20 dB pad

and 48V phantom power settings that you can also

control from the UltraLite-mk3 front panel TRIM

encoders. There are separate settings for each mic

input.

Tabs for the channel that

currently has the focus

Tabs for the global meter

bridge and reverb processor
