CHAPTER
13
2 Packing List and Windows System
Requirements
PACKING LIST
The UltraLite-mk3 ships with the items listed
below. If any of these items are not present in your
UltraLite-mk3 box when you first open it, please
immediately contact your dealer or MOTU.
■ One UltraLite-mk3 I/O rack unit
■ One 6-pin to 6-pin IEEE 1394 “FireWire” cable
■ One USB cable
■ One set of removable rack ears
■ One UltraLite-mk3 Mac/Windows manual
■ One AudioDesk Manual
■ One cross-platform CD-ROM
■ Product registration card
WINDOWS SYSTEM REQUIREMENTS
The UltraLite-mk3 system requires the following
Windows system:
■ A 1 GHz Pentium-based PC compatible or faster
equipped with at least one FireWire port
■ A Pentium III processor or faster is
recommended
■ At least 256 MB (megabytes) of RAM (512 MB
or more is recommended)
■ Windows XP or Vista
■ A large hard drive (preferably at least 250 GB)
PLEASE REGISTER TODAY!
Please register your UltraLite-mk3 today. There are
two ways to register.
■ Visit www.motu.com/registration to register on
line
OR
■ Fill out and mail the included product
registration card
As a registered user, you will be eligible to receive
technical support and announcements about
product enhancements as soon as they become
available. Only registered users receive these
special update notices, so please register today!
Thank you for taking the time to register your new
MOTU products!
