MOTU ULTRALITE MKIII HYBRID [53/112] Bit operation

SONAR AND OTHER WDM SOFTWARE

input source and output destination in your

WDM-compatible software’s MIDI input and

output menus.

24-BIT OPERATION

Your UltraLite-mk3 hardware fully supports 24-bit

recording in any audio software that supports it.

Simply enable 24-bit operation as instructed by the

software. The UltraLite-mk3 system always

supplies the software with a 24-bit data stream, and

when you enable 24-bit operation, it simply uses all

24-bits supplied by the UltraLite-mk3 hardware.
