MOTU ULTRALITE MKIII HYBRID [48/112] Bit operation

CUBASE, NUENDO, LIVE AND OTHER ASIO SOFTWARE

24-BIT OPERATION

Your UltraLite-mk3 hardware fully supports

Cubase and Nuendo’s 24-bit recording capabilities.

Simply enable 24-bit operation as instructed in

your Cubase or Nuendo manual. The

UltraLite-mk3 always supplies a 24-bit data

stream, and when you enable 24-bit operation in

Cubase or Nuendo, it simply uses all 24-bits

supplied by the UltraLite-mk3 hardware.
