ULTRALITE-MK3 HYBRID FRONT PANEL OPERATION
42
OUTPUTS MENU MIXES MENU
REVERB MENU
STAND-ALONE OPERATION
All settings, including all mix settings and global
settings, are saved in the UltraLite-mk3’s memory,
and they remain in effect even when the
UltraLite-mk3 is not connected to a computer.
This allows you to use the UltraLite-mk3 as a
stand-alone 8-bus mixer. You can make
adjustments to any setting at any time from the
front panel.
CHANNEL PAGE PARAM
OUTPUTS
Main
Analog 1-2
Analog 3-4, etc.
EQ
(global)
ENABLE
COPY
PASTE
RESET
HPF
(High-pass)
ENABLE
SLOPE
FREQ
LF
(Low w/shelf)
ENABLE
TYPE
FREQ
GAIN
WIDTH
LMF
(Low-mid)
ENABLE
TYPE
FREQ
GAIN
WIDTH
MF
(Mid)
ENABLE
TYPE
FREQ
GAIN
WIDTH
HMF
(High-mid)
ENABLE
TYPE
FREQ
GAIN
WIDTH
HF
(High w/shelf)
ENABLE
TYPE
FREQ
GAIN
WIDTH
LPF
(Low-pass)
ENABLE
SLOPE
FREQ
DYN
(Dynamics)
ENABLE
COPY
PASTE
RESET
COMP
(Compressor)
ENABLE
MODE
THRESH
RATIO
ATTACK
RELEASE
TRIM
LEVELER ENABLE
MODE
REDUCE
MAKEUP
REVERB SEND
SEND PAN
MASTER MONITOR
TALKBACK
LSNBACK
CHANNEL PAGE PARAM
MIXES
Mix 1
Mix 2
etc.
MASTER ASSIGN
MUTE
FADER
COPY
PASTE
RESET
REVERB SEND
RETURN
ANALOG 1
ANALOG 2
etc.
(if mono)
MUTE
SOLO
(BAL/WID) - n/a
PAN
FADER
ANALOG 3-4
ANALOG 5-6
etc.
(if stereo)
MUTE
SOLO
BAL/WID
BAL
FADER
SP (S/PDIF) MUTE
SOLO
BAL/WID
BAL
FADER
CHANNEL PAGE PARAM
REVERB --- ENABLE
TIME
PREDELAY
WIDTH
CUT Hz
CUT dB
ROOM
REFSIZE
REF LEV
LO %
MID %
HI %
LO XOVR
HI XOVR
SPLIT
