![Tascam GT-R1 [104/112] Gt r1 messages](/views2/2007950/page104/bg68.png)
104 TASCAM GT-R1
22–GT-R1 Messages
The following is a list of the popup messages
that might appear on the GT-R1 under certain
conditions.
Refer to this list if one of these popup messages
appears and you want to check the meaning or
determine a proper response.
Message Meaning and response
File not
found
The audio le cannot be found or is corrupted. Check the le (using a computer).
Non-
Supported
The audio le is not a supported format. Check the le format (using a computer).
Battery
Empty
The battery is almost out of power. Use a USB connection or an AC adapter (sold
separately) to recharge it.
I/O Too
Short
When using the I/O key, the IN and OUT points are too close together to start loop
playback. Reset the IN and OUT points and try again.
File Not
Found
PLAYLIST
The le in the Playlist cannot be found. Please conrm that the le is still in the
Music Folder.
No
PLAYLIST
No les are in the Playlist. This appears when the
PLAY MODE
is set to
PLAYLIST
, but no les have been added to the Playlist. Add a le to the Playlist.
See “Adding tracks to the playlist” on page 60.
PLAYLIST
FULL
You cannot add more than 99 tracks to the Playlist. Erase an unneeded le from the
Playlist and then add the new le. See “Editing the playlist” on page 61.
