108 TASCAM GT-R1
23–Specifications
Audio Input and Output
GUITAR IN input
Jack 1/4˝, mono, unbalanced
Input impedance 1 MΩ or more
Nominal input level -26 dBV
Maximum input level -10 dBV
MIC IN input
Jack 3.5-mm stereo phone (with plug-in power)
Input impedance 30 kΩ
Nominal input level -64 dBV (GAIN set to HIGH)
-48 dBV (GAIN set to MID)
-32 dBV (GAIN set to LOW)
Maximum input level -48 dBV (GAIN set to HIGH)
-32 dBV (GAIN set to MID)
-16 dBV (GAIN set to LOW)
LINE IN input
Jack 3.5-mm phone (stereo)
Input impedance 23 kΩ
Nominal input level -10 dBV
Maximum input level +6 dBV
/LINE OUT output
Jack 3.5-mm phone (stereo)
Nominal line output -14 dBV
Maximum line output +2 dBV
Maximum headphones output 15 mW + 15 mW (with 32 Ω impedance headphones)
