50 TASCAM GT-R1
7–Recording
NOTE
If you have set the Input Setting Screen’s
MONITOR item to ON so that you can always
monitor the input, a pop-up appears that allows
you to turn overdubbing ON or OFF.
For ordinary recording, select OFF and continue
to step 2.
2 To start ordinary recording, press the
REC/PAUSE key again.
When recording starts, the REC/PAUSE
key lights continuously, and the display
shows the elapsed recording time and the
remaining recording time.
3 Press the STOP/HOME key to end recording
and create the audio file.
• Topauserecording,presstheREC/PAUSE
key. Press the REC/PAUSE key again to
restart recording in the same track. If you
press the STOP/HOME key after pausing a
recorded audio file up to the moment that
you paused recording is created.
Overdubbing
You can perform along while playing a saved audio
le and record the combined sound mixed together
as a new le. See “8–Playback” for information
about how to select the playback le, adjust the
monitoring volume and make other settings.
Preparation for overdubbing
Follow these procedures to prepare to overdub.
Set the file type to WAV
Only WAV les can be created by overdubbing.
1 Press MENU to open the Menu Screen.
2 Use the wheel to select
REC SETTING
(highlighted in inverse) and press ¥/ π .
