SOLID STATE LOGIC Alpha Link MX 16-4 [25/52] Anschliessen
![SOLID STATE LOGIC Alpha Link MX 16-4 [25/52] Anschliessen](/views2/2007973/page25/bg19.png)
19
EN
DE
ES
FR
IT
JP
Anschliessen
Für die Pinbelegung schauen sie bitte auf Seite 3.
Unit ID Switch (MADI Verbund)
Dip Schalter Funktion
Erste Einheit im MADI Verbund
(default)
Zweite Einheit im MADI Verbund
Dritte Einheit im MADI Verbund
Vierte Einheit im MADI Verbund
16 Analoge Eingänge
4 Analoge
Ausgänge
16 Analoge Ausgänge
4 Analoge
Eingänge
Alpha-Link
MX 16-4
Alpha-Link
MX 4-16
USB
(nur für Firmware-Upgrades)
MADI I/O
Wordclock-Eingang,
Wordclock-Ausgang
Netzbuchse
