仕様
Connections (接続)
一次側電源IEC3203ピンコネクター、AC100~240V、50/60Hz
I/O25ピンDサブコネクター(ソケット)、Zi>10kΩ、Zo≈100Ω
MADI1×ツインSC型シャーシのソケット、
ガラスマルチモードファイバ50/125µ（65/125µ互換）
USB1xTypeBソケット(Firmwareのアップデート専用)
ワードクロック75ΩBNC、3.3V/5VTTLコンパチブル
Performance (性能)
AD/DA変換24bit、固定小数点
アナログ入出力レベルバランス、+14dBu〜+24dBu=0dBFS
(フロントパネルから選択できます)
Physical (寸法)*
奥行き220mm/8.75"本体のみ
高さ45mm/1.75"(1U)
幅435mm/17"本体のみ
482mm/19"ラックマウントアングル付き
質量2.8kg/6.25pounds
消費電力<25Watts
箱のサイズ635mmx320mmx150mm
25"x12.75"x6"
箱の質量(内容物含む)4.5kg/10pounds
*全ての数値はおおよその値です。
Environmental (使用環境)
温度使用時+5~30°C
非使用時–20~50°C
温度勾配15°C/時
相対湿度使用時20~80%
非使用時5~90%
最大湿球温度29°C
(非凝縮)
振動使用時<0.2G(3~100Hz)
非使用時<0.4G(3~100Hz)
衝撃使用時<2G(最大10ms)
非使用時<10G(最大10ms)
設置高度使用時0~3000m
(海抜)非使用時0~12000m
