![SOLID STATE LOGIC Alpha Link MX 16-4 [49/52] 接続](/img/pdf.png)
SOLID STATE LOGIC Alpha Link MX 16-4 [49/52] 接続
![SOLID STATE LOGIC Alpha Link MX 16-4 [49/52] 接続](/views2/2007973/page49/bg31.png)
43
EN
DE
ES
FR
IT
JP
接続
各コネクターのPin配列はP3を参照してください。
ユニットIDスイッチ（MADIループスルー）
ポジション機能
MADIチェーンの1台目
（デフォルト）
MADIチェーンの2台目
MADIチェーンの3台目
MADIチェーンの4台目
アナログ入力16系統
アナログ出力4系統
アナログ出力16系統
アナログ入力4系統
Alpha-Link
MX 16-4
Alpha-Link
MX 4-16
USB
(firmwareのアップデート時のみ使用します)
MADI入出力
Wordclock入力、
Wordclock出力
AC 電源
