SOLID STATE LOGIC Alpha Link MX 16-4 [9/52] Connectors
![SOLID STATE LOGIC Alpha Link MX 16-4 [9/52] Connectors](/views2/2007973/page9/bg9.png)
3
EN
DE
ES
FR
IT
JP
Connectors
† D-type connector binding posts are 4-40 UNC thread.
Analogue I/O 1 - 8
†
Connector Type: 25-way D-type Female
Pin Description
1 Channel 8 (+ve)
14 Channel 8 (–ve)
2 0V
15 Channel 7 (+ve)
3 Channel 7 (–ve)
16 0V
4 Channel 6 (+ve)
17 Channel 6 (–ve)
5 0V
18 Channel 5 (+ve)
6 Channel 5 (–ve)
19 0V
7 Channel 4 (+ve)
20 Channel 4 (–ve)
8 0V
21 Channel 3 (+ve)
9 Channel 3 (–ve)
22 0V
10 Channel 2 (+ve)
23 Channel 2 (–ve)
11 0V
24 Channel 1 (+ve)
12 Channel 1 (–ve)
25 0V
13 n/c
Analogue I/O 9 - 16
†
Connector Type: 25-way D-type Female
Pin Description
1 Channel 16 (+ve)
14 Channel 16 (–ve)
2 0V
15 Channel 15 (+ve)
3 Channel 15 (–ve)
16 0V
4 Channel 14 (+ve)
17 Channel 14 (–ve)
5 0V
18 Channel 13 (+ve)
6 Channel 13 (–ve)
19 0V
7 Channel 12 (+ve)
20 Channel 12 (–ve)
8 0V
21 Channel 11 (+ve)
9 Channel 11 (–ve)
22 0V
10 Channel 10 (+ve)
23 Channel 10 (–ve)
11 0V
24 Channel 9 (+ve)
12 Channel 9 (–ve)
25 0V
13 n/c
Analogue I/O 1 - 4
†
Connector Type: 25-way D-type Female
Pin Description
1 n/c
14 n/c
2 0V
15 n/c
3 n/c
16 0V
4 n/c
17 n/c
5 0V
18 n/c
6 n/c
19 0V
7 Channel 4 (+ve)
20 Channel 4 (–ve)
8 0V
21 Channel 3 (+ve)
9 Channel 3 (–ve)
22 0V
10 Channel 2 (+ve)
23 Channel 2 (–ve)
11 0V
24 Channel 1 (+ve)
12 Channel 1 (–ve)
25 0V
13 n/c
