Spécifications
Mesures *
Profondeur 220mm / 8,75"
boîtier seul
Hauteur 45mm / 1,75" (1UH)
Largeur 435mm / 17"
boîtier seul
482mm / 19"
incl. oreilles de support
Poids 2,8kg / 6,25 livres
Puissance élec. < 25 Watts
Taille emballage 635mm x 320mm x 150mm
25" x 12,75" x 6"
Poids emballage 4,5kg / 10 livres
* Toutes valeurs approximatives
Environnement
Température En marche: +5 à 30 deg C
A l’arrêt: –20 à 50 deg C
Augment. max.: 15 deg C/heure
Humidité rel. En marche: 20 à 80%
A l’arrêt: 5 à 90%
Max. therm. bulbe: 29 deg C
(non condensant)
Vibration En marche: < 0,2 G (3 – 100Hz)
A l’arrêt: < 0,4 G (3 – 100Hz)
Choc En marche: < 2 G (10 ms max.)
A l’arrêt: < 10 G (10 ms max.)
Altitude (au de. En marche: 0 – 3000m
niv. de la mer) A l’arrêt: 0 – 12000m
Connexions
Alimentation Connecteur à 3 broches IEC320, 100 – 240 Vac, 50 – 60 Hz
E/S analogiques Connecteur 25-pin D-type, Zi > 10kΩ, Zo ≈ 100Ω
MADI E/S 1 x fiche de chassis double, type SC,
fibre de verre multimode 50/125µ (compatible 65/125µ)
USB 1 x prise femelle type-B
(pour mises à jour du firmware)
Sync 75Ω BNC, Zi ≈ 75Ω, 3V3/5V compatible TTL
Performance
Quantisation 24bit, virgule fixe
Niveau d’entrée/sortie Symétrique, +14dBu à +24dBu max.
(sélection sur le panneau avant)
