ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Penta Pix Specifications
Model:
Penta Pix
Voltage: 100V~240V 50/60Hz
LEDs: 5 x 15W 4-in-1 RGBW Quad LEDs
Beam Angle: 6 Degrees
Power Consumption: 77W
Fuse: 2Amp
Power Cord Daisy Chain: 13 Fixtures Max. (120V)
25 Fixtures Max. (230V)
Weight: 16lbs./ 7.1Kgs.
Dimensions: 21” (L) x 9” (W) x 10.25” (H)
530 x 230 x 260mm
Colors: RGBW
DMX Channels: 5 DMX Modes: 4/8/11/20/27
Working Position: Any safe working position
Warranty: 2 Years (730 days)
Please Note: Specications and improvements in the design of
this unit and this manual are subject to change without any prior
written notice.
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC - www.adj.com - Penta Pix Instruction Manual Page 26
