32 33XENYX UFX1604 Quick Start Guide
FireWire and USB recording Recording to USB drive in STAND-ALONE mode
(EN) Step 6: FireWire and
USB recording
(EN) Step 7: Recording
to USB drive in
STAND-ALONE
mode
Your mixer is equipped with AD/DA converters,
FireWire and USB connections for sending audio to
and from your computer.
Make sure the drivers for the UFX1604 are
loaded on your Windows computer
(driver is not required for Mac OS X).
Connect the mixer to the computer via
FireWire or USB. Make sure you set the
3-way switch on the back panel of the
mixer accordingly.
Select the UFX1604 inputs and outputs
you’d like to use in your
recording software.
Set your desired sample rate and
bitdepth from within your DAW
(digitalaudio workstation) software.
Connect your microphones, instruments
and line level sources to the channel
inputs. Each channel can be recorded pre
or post EQ as its own mono or stereo track in your
recording software. It is also possible to record the
AUX sends on channels 13/14.
The MAIN Mix can also be recorded by pressing the
MAIN MIX ASSIGN TO FW 15-16 button. This will send
the main mix to your DAW through output 15/16.
Arm the tracks in your recording software
and record when ready.
Make sure the STAND ALONE mode is
selected on the back of the mixer
(centerposition).
When a new USB drive is inserted for
the rst time, the mixer tests the
writing speed of the drive to determine
the audio quality. The outcome appears on the
TRANSPORT CONTROL screen as “Lo” (16 bit) or “Hi”
(24 bit). If the drive is too slow for recording,
thedisplay will show “SLO” after testing.
If your drive needs to be formatted,
press and simultaneously on
the TRANSPORT CONTROL until the
display reads, “For” (blinking). Push to initiate
formatting or to abort.
To show the sample rate setting,
push and hold the TIME REMAIN button
until the sample rate is displayed.
To change the sample rate to 44.1 kHz,
push and hold TIME REMAIN until the
sample rate appears and then
press while still holding TIME REMAIN.
To change the sample rate to 48 kHz,
push TIME REMAIN until the sample
rate appears and then press while
still holding TIME REMAIN.
With all your microphones,
instruments and source signals
connected press the button on the
TRANSPORT CONTROL to create a new folder on the
USB drive with the individual channels as les.
Congratulations! You are now recording.
Press when nished.
The recordings are displayed on the
TRANSPORT CONTROL screen as
numbers (1-99).
To toggle between recording and
playlist modes, press TIME REMAIN
and at the same time for
two seconds.
To listen or navigate through recordings
you have made, you must be in
recording mode. Playlist mode is ONLY
for playing back WAV les you copied to your drive
from a PC/Mac.
While in recording mode, press to hear
whatyou just recorded. To return to the start,
pressthe button on the TRANSPORT CONTROL
once. Press twice to move to the previous
recording. Press to move to the start of
the next recording. Note: long push on the
or will not fast forward or rewind within
the track. ONLY tracks 15 and 16 will be played
back on channels 15 and 16 unless you route the
MAINMIX signal to FW 15-16 (in the MAIN MIX
ASSIGN section). This allows the MAIN MIX signal to
be recorded and played back via channels 15 and
16. In this conguration, channels/buttons for 13
and 14 are bypassed.
To toggle between single playback
and continuous playback mode (in
playlist mode), long press PLAY.
To delete the current song in recording
mode, playback or recording must be
stopped. Press and together.
Press to complete deletion or to cancel.
IMPORTANT NOTE: the USB recorder
only plays songs if they are .wav les
with sample rates of 44.1 or 48.0 kHz
from the folder labeled “MyWav.” No subfolders
are accepted.
