Operating The goRack

This section of the manual describes the processing types available and how to operate the goRack.

Master Volume

When the goRack initially boots, the VOLUME encoder will control master output volume. This is the default operating mode.

Volume is controlled post-compression and pre-limiting.

To adjust master volume:

1. Turn the VOLUME encoder clockwise to raise the output volume or

counter-clockwise to lower the volume.

ANTI-FEEDBACKMUTE

VOLUME

(EDIT)

MODE

EQCOMPRESSOR

(HOLD) EDIT

SUB SYNTH

INPUT

SIGNAL

LEFT RIGHT

9 9

Output Limiter & Clipping

A non-editable limiter is in place on the outputs to prevent harsh digital clipping. You may hear the limiter affecting the signal if

your output levels get too close to clipping.

A small dot in the lower right hand corner of the display will light if the output channels are driven

into clipping. This occurs if you have added too much gain to your signal via the Compressor, Sub

Synth, or EQ processing modules. If you see this dot light, your signal is clipping and you need to

turn it down. The easiest way to do this is to lower the master volume using the VOLUME encoder.

You may also want to adjust your input gains, Compressor amount, Sub Synth amount, or EQ

setting to help avoid clipping.
