PERFORMANCE PROCESSOR

Application 3: Band Performance/DJ

This application is suited for band rehearsal spaces, small venue live performances, or small DJ applications where the

sound system already consists of a dedicated mixer and the goRack is used for system processing only. The goRack’s two

combination MIC/LINE inputs can be connected to the mixer’s left/right master outputs. Stereo imaging will be maintained

through the system when using the LEFT/RIGHT inputs and the pan pots on the mixer can be used to place sound sources in

the stereo field if required.

Application Notes:

• Make sure your mixer and powered speakers (or amplifiers) are turned off before making connections.

• Make connections as described in ‘Making Connections’ on page 5 then apply power to the system according

to the instructions described in ‘Applying Power’ on page 5.

• The routing 2 option will work best for this application. See ‘Configuring The goRack’s Routing’ on page 6 for

information on goRack routing options.

Mixer

Left Master Out

Line Inputs

Right Master Out

Set to

LINE

Set to

LINE

Powered

Speaker

Powered

Speaker

Mixer Connections

Included Harman

Power Adapter

NOTE: For best noise performance, balanced cables (XLR or 1/4” TRS Phone) should be used between the mixer and

goRack if the mixer’s outputs are balanced. See ‘Audio Cable Diagrams’ on page 26 for more information on these

cable types.
