REDUCED SIZE BACK COVER FOLDOUT FOR ELECTROPHONIC PILOT'S GUIDE
OUTPUT
LEVEL
TREBLE
BASS CHAN VOL
REVERBDRIVE
EFFECT
TWEAK
MIDDLE
ROTARY
FLANGER 2
FLANGER 1
CHORUS 2
CHORUS 1
TREMOLO
COMPRESSOR
DELAY/COMPRESSOR
DELAY/TREMOLO
DELAY/CHORUS 1
DELAY/CHORUS 2
DELAY/FLANGER 1
DELAY/FLANGER 2
DELAY/SWELL
BLACK PANEL
TWEED BLUES
SMALL TWEED
LINE 6 LAYER
LINE 6 DRIVE
LINE 6 CRUNCH
LINE 6 CLEAN
BRIT CLASS A
BRIT BLUES
BRIT CLASSIC
BRIT HI GAIN
RECTIFIED
MODERN HIGAIN
FUZZ BOX
DELAY
EFFECTS
MODERN CLASS A
AMP MODELS
010 010
010
010
010
010
010
010
BYPASSTUBE PREAMP
POD
THE ULTIMATE GUITAR DIRECT BOX
Version 2.0
P
H
O
N
E
S
L
E
F
T
P
E
D
A
L
A
.
I
.
R
.
M
O
D
E
R
I
G
H
T
D
I
R
E
C
T
/
A
M
P
M
I
D
I
M
I
D
I
P
O
W
E
R
I
N
P
U
T
O
U
T
P
U
T
O
UT
P
U
T
I
N
O
U
T
2x12
1x12
4x10
4x12
1x8
O
F
F
(
AMP MODELS 17 – 32
)(
CAB SELECT
)
TUNER
MIDI
NOISE
GATE
MANUAL SAVE
TAP
(HOLD)
AB
CD
EDITED
6
* Fender, Marshall, Vox, Budda, Dumble, Matchless, Mesa Boogie, Soldano, Roland, Arbiter, and other amplifier and effect models are all trademarks of their respective owners, which are in no way associated or affiliated with Line 6. These trademarks of other manufacturers are used solely for the purpose of describing certain
amplifier and effect tones produced using Line 6's modeling technology. Line 6's modeling technology provides POD with a wide variety of sounds and effects modeled after some of the most popular sounds of these classic amps. Line 6, POD, Floor Board, the Line 6 logo and the POD logo are trademarks of Line 6, Inc.
EFFECT SETUPS
Effect Tap Tweak Notes
Bypass n/a n/a Turns off the effects
Compressor n/a Ratio Higher settings
"squeeze" your volume
more.
Tremolo Tremolo Speed Depth The tremolo was
designed with the
characteristic Fender
shape.
Chorus 1 Chorus Speed Range of Square wave LFO,
choruses "rack" type chorus
setup; subtler than
Chorus 2
Chorus 2 Chorus Speed Range of Sine wave LFO, approx.
choruses 10% feedback; emulates
an old Roland CE-1 for
classic stomp box sound.
Flanger 1 Flanger Speed Range of Light Flange
flangers
Flanger 2 Flanger Speed Range of Heavier flange with
flangers more feedback.
Rotary Speaker Rotary Speed Depth This emulates a classic
spinning speaker, a la
the Leslie
Delay Delay Time Delay Level Very quick delays will
have no repeats for
better slapback
Delay Swell Delay Time Swell Time Volume swell
FLEXTONE: TAP LIT BUTTON FOR TAP TEMPO / HOLD LIT BUTTON FOR MANUAL
29
23
24
25 2627
28
AMP MODELS
*
Amp Model Based on: Volume Pedal Reverb
Line 6 Clean Line 6 21st Century Clean Pre Room
Line 6 Crunch Line 6 Thick Grindage Pre Spring
Line 6 Drive Line 6 Industrial Strength Overdrive Post Room
Line 6 Layer Line 6 Clean meets Psychotic Drive Post Room
Small Tweed 1952 Fender Tweed Deluxe Pre Room
Tweed Blues 1959 Fender Bassman Pre Spring
Black Panel 1964 Blackface Fender Deluxe Pre Spring
Modern Class A 1996 Matchless Chieftain Pre Spring
Brit Class A 1960 Vox AC 15 Pre Room
Brit Blues 1964/65 Marshall JTM-45 Pre Room
Brit Classic 1968 Marshall “Plexi” Pre Room
Brit Hi Gain 1986 Marshall JCM 800 Post Room
Rectified 1994 Mesa Boogie Dual Rectifier Post Room
Modern Hi Gain 1989 Soldano SLO Super Lead Overdrive Post Room
Fuzz 1960s Arbiter Fuzz Face Post Room
Tube Preamp Tube-based instrument preamp Post Room
(Hold Tap and turn to this position) for Amp Models 17-32:
(Line 6 Clean) Line 6 Twang Fender Deluxe and Bassman Pre Spring
(Line 6 Crunch) Line 6 Crunch #2 ’68 Marshall Plexi 50 watt Pre Room
(Line 6 Drive) Line 6 Blues Marshall JTM-45 meets Budda Twinmaster Pre Room
(Line 6 Layer) Line 6 Insane Way too many hours of shredding Post Room
(Small Tweed) Small Tweed #2 ’60 Tweed Fender Champ Pre Room
(Tweed Blues) Boutique #3 Budda Twinmaster head Pre Room
(Black Panel) Black Panel #2 ’65 Blackface Fender Twin Pre Spring
(Modern Class A) Brit Class A #3 ’60 Vox AC 15 Pre Room
(Brit Class A) Brit Class A #2 ’60 Vox AC 30 non-Top Boost Pre Room
(Brit Blues) California Crunch #1 ’85 Mesa Boogie Mark IIc+ Clean Channel Pre Spring
(Brit Classic) California Crunch #2 ’85 Mesa Boogie Mark IIc+ Drive Channel Post Spring
(Brit Hi Gain) Boutique #1 Dumble Overdrive Special Clean Channel Pre Room
(Rectified) Rectified #2 ’95 Mesa Boogie Dual Rectifier Head Post Room
(Modern HiGain) Modern HiGain #2 ’89 Soldano SLO Super Lead Overdrive Post Room
(Fuzz Box) Boutique #2 Dumble Overdrive Special Drive Channel Post Room
(Tube Preamp) Jazz Clean 1987 Roland JC-120 Jazz Chorus Post Room
6U
1
3
4
5
7
8
9
11
12
13
14
15
17
16
18 19
20
2122
6
2
5
