APPENDIX D: MIDI CONTROLS (2 of 3 pages)
Sound Diver
Parameters
Notes
Transmitted MIDI
Range
Control
#
Received MIDI Range
Delay (always available) On/Off FB SWITCH ON=127 28 Rcv: 0-63=OFF, 64-127=ON
Delay Time 0-3150 mS, 128 equal
steps
NO TRANSMIT 30 0-127
Double-precision
control for Delay Time
with Delay Time,
gives 14 bit precision
NO TRANSMIT 62 0-127
Delay Repeats - 0-127 32 0-127
Delay Level - 0-127 34 0-127
Reverb (always available) On/Off FB SWITCH ON=127 36 Rcv: 0-63=OFF, 64-127=ON
Reverb Type Spring/Hall NO TRANSMIT 37 Rcv: 0-63=SPRING, 64-
127=HALL
Reverb Decay - 0-127 38 0-127
Reverb Tone - NO TRANSMIT 39 0-127
Reverb Diffusion - NO TRANSMIT 40 0-127
Reverb Density - NO TRANSMIT 41 0-127
Reverb Level - 0-127 18 0-127
Compression Ratio off, 1.4:1, 2:1,
3:1, 6:1, infinity:1
NO TRANSMIT 42 0-21=off, 22-44=1.4:1,
45-67=2:1, 68-90=3:1,
91-113=6:1, 114-127= infinity:1
Wah Wah Pedal On/Off On/Off FB SWITCH ON=127/
OFF=0
43 Rcv: 0-63=OFF, 64-127=ON
Wah Pedal - 0-127 4 0-127
Wah Bottom Frequency - NO TRANSMIT 44 0-127
Wah Top Frequency - NO TRANSMIT 45 0-127
Volume Pedal - 0-127 7 0-127
Volume Pedal Minimum - NO TRANSMIT 46 0-127
Volume Pedal Location Pre Tube Drive /
Post Tube Drive
NO TRANSMIT 47 Rcv: 0-63=BEFORE TUBE,
64-127=AFTER TUBE
Volume Swell On/Off On/Off NO TRANSMIT 48 Rcv: 0-63=OFF, 64-127=ON
Volume Swell Ramp Time - NO TRANSMIT 49 0-127
Tap Tempo - TAP BUTTON OR FB
SWITCH TRANSMITS 127
64 64-127= a Tap
