MODELED AMPS & CABS: WHICH AMPS AND CABS ARE MODELED?
4 • 12
Cabinet Models - The following Cabinet Models are available on POD,
and are accessed by holding the Ta p button and turning the Effects knob:
The Cabinet Model is automatically selected by the Amp Model. You can
customize these Amp/Cabinet pairings, as described in Chapter 6.
1x8 1960 Fender Tweed Champ
1x12s 1952 Fender Tweed Deluxe
1960 Vox AC-15
1964 Fender Blackface Deluxe
Line 6 1x12
2x12s 1965 Fender Blackface Twin
1967 Vox AC-30
1995 Matchless Chieftain
Line 6 2x12
4x10s 1959 Fender Bassman
Line 6 4x10
4x12s 1996 Marshall with Vintage 30s
1978 Marshall with stock 70s
1968 Marshall Basketweave with Greenbacks
Line 6 4x12
No Cab You will probably want to use this Cabinet model with the
Tube Preamp model for non-guitar sources. It is selected
by default when you pull up the Tube Preamp Amp Model.
