7. Accessories
RME offers several optional components. Additionally parts of the HDSP 9632, like the special
breakout cables, are available separately.
Part Number Description
36003 Optical cable, TOSLINK, 0.5 m (1.6 ft)
36004 Optical cable, TOSLINK, 1 m (3.3 ft)
36006 Optical cable, TOSLINK, 2 m (6.6 ft)
36007 Optical cable, TOSLINK, 3 m (9.9 ft)
36008 Optical cable, TOSLINK, 5 m (16.4 ft)
36009 Optical cable, TOSLINK, 10 m (33 ft)
Standard lightpipe with TOSLINK connectors, RME approved quality.
BO9632 Breakout cable SPDIF (RCA)
BO968 Breakout cable AES (XLR)
BO9632-CMKH Breakout cable Analog (RCA)
BO9632-XLRMKH Breakout cable Analog (XLR)
8. Warranty
Each individual Hammerfall DSP undergoes comprehensive quality control and a complete test
at IMM before shipping. The usage of high grade components allow us to offer a full two year
warranty. We accept a copy of the sales receipt as valid warranty legitimation.
If you suspect that your product is faulty, please contact your local retailer. The warranty does
not cover damage caused by improper installation or maltreatment - replacement or repair in
such cases can only be carried out at the owner’s expense.
Audio AG does not accept claims for damages of any kind, especially consequential damage.
Liability is limited to the value of the Hammerfall DSP. The general terms of business drawn up
by Audio AG apply at all times.
