10.4 Firmware Update

The Flash Update Tool updates the HDSP 9632 to the latest firmware version. It requires an

already installed driver.

Start the program hdsp_fut.exe. The Flash Update Tool displays the current revision of the

HDSP 9632, and whether it needs an update or not. If so, then please press the 'Update' but-

ton. A progress bar will indicate when the flash process is finished. The bar moves slowly first

(program), then faster (verify).

If more than one interface card is installed, all cards can be flashed by changing to the next tab

and repeating the process.

After the update the PCI card need to be resettet. This is done by powering down and shutting

off the PC. A warm boot is not enough!

When the update fails (status: failure), the card's second BIOS will be used from the next cold

boot on (Secure BIOS Technology). Therefore the card stays fully functional. The flash process

should then be tried again on a different computer.

Note

: Because of the changed hardware revision, Windows 2000/XP will start the hardware

assistant and wants to install new drivers. Do NOT let Windows search for new drivers, but

follow the instructions given in chapter 10.2.

11. Configuring the HDSP 9632

11.1 Settings Dialog

Configuration of the HDSP system HDSP 9632 is done via its own settings dialog. The panel

'Settings' can be opened:

• by clicking on the hammer symbol in the Task Bar's system tray

The mixer of the Hammerfall DSP Systems (TotalMix) can be opened:

• by clicking on the mixer icon in the Task Bar's system tray

The hardware of the HDSP system offers a number of helpful, well thought-of practical functions

and options which affect how the card operates - it can be configured to suit many different

requirements. The following is available in the 'Settings' dialog:

• Input selection

• Level of analog I/Os

• Configuration of digital I/Os

• Synchronization behaviour

• State of input and output

• Current sample rate

• Latency

Any changes made in the Settings dialog are applied immediately - confirmation (e.g. by click-

ing on OK or exiting the dialog) is not required. However, settings should not be changed during

playback or record if it can be avoided, as this can cause unwanted noises. Also, please note

that even in 'Stop' mode, several programs keep the recording and playback devices open,

which means that any new settings might not be applied immediately.

The status displays at the bottom of the dialog box give the user precise information about the

current status of the system, and the status of all digital signals.
