64 XENY X UFX1204 Quick Start Guide 65
SpecicationsSpecications
Mono Inputs
Microphone inputs (XENYX mic preamp) 4
Type
XLR , electronically balanced,
discrete input circuit
Mic E.I.N.
1
(20 Hz - 20 kHz)
@ 0Ω source resistance -129 dB / 131 dB A-weighted
@ 50Ω source resistance -128 dB / 130 dB A-weighted
@ 150Ω source resistance -127 dB / 129 dB A-weighted
Frequency response
<10 Hz – 140 kHz (-1 dB)
<10 Hz – 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx 2.06 kΩ balanced
Signal-to-noise ratio
110 dB A-weighted
(-10 dBu in @ +32 dB gain)
Distortion (THD+N) 0.0045% (-20 dBu in @ +20 dB gain)
Phantom power +48 V, switchable per mic channel
Hi-Z input impedance 1 MΩ
Line Inputs
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -10 dB to +40 dB
Max. input level 30 dBu
Stereo Inputs
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu
CD/Tape In
Type RCA connector
Impedance 10 kΩ
Max. input level +22 dBu
EQ Mono Channels
Low 80 Hz / ±15 dB
Mid 100 Hz to 8 kHz / ±15 dB
High 12 kHz / ±15 dB
Low cut 80 Hz,18 dB/oct.
EQ Stereo Channels
Low 80 Hz / ±15 dB
Low mid 300 Hz / ±15 dB
High mid 3 kHz / ±15 dB
High 12 kHz / ±15 dB
Channel Inserts
Type ¼" TRS connector, unbalanced
Max. input level +22 dBu
Crosstalk
Main fader closed 90 dB
Channel muted 88 dB
Channel fader closed 88 dB
Aux Sends
Type ¼" TS connector, unbalanced
Impedance 120 Ω
Max. output level +22 dBu
Aux Returns
Type ¼" TRS connector, balanced
Impedance 20 kΩ balanced, 10 kΩ unbalanced
Max. input level +22 dBu
Main Outputs
Type XLR and 1/4'' TRS balanced
Impedance 240 Ω balanced, 120 Ω unbalanced
Max. output level +28 dBu
Control Room Output
Type ¼" TS connector, unbalanced
Impedance 120 Ω
Max. output level +22 dBu
Dual Phones Output
Type ¼" TRS connector, unbalanced
Max. output level +22 dBu / 23 Ω - 300 mW @ 100 Ω
CD/Tape Out
Type RCA connector
Impedance 1 kΩ
Max. output level +22 dBu
Eects
Converters
24-bit Delta-Sigma,
128-times oversampling
Sampling rate 48 kHz
FireWire/USB Interface
Operation modes FireWire 400 or USB 2.0
Connectors
6-pin FireWire 400 (IEEE1394A),
USB 2.0 Type B
Converters 24-bit
Sample rate 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Channel number 16 x 4 in/out
Operating systems Windows XP or higher, Mac OS X
Low latency audio support ASIO (Win), CoreAudio (Mac)
Transport section MIDI control
Standard MIDI mode
(CC/note commands)
or Mackie control mode
USB Recorder (Stand Alone Mode)
Connector USB 2.0 (Type A)
Storage device
External USB 2.0 hard-disk drive
(operation depends on required
power consumption)
Sample rate 44.1 kHz, 48 kHz
File format WAV (uncompressed)
File system FAT 16 / FAT 32
Number of recorded channels 16 tracks (stored as mono WAV les)
Power Supply
Mains voltage 100 - 240 V~, 50/60 Hz
Power consumption 60W
Fuse (100 - 230V~, 50/60Hz) T 2A H 250 V
Mains connector Standard IEC receptacle
Physical/Weight
Dimensions (H x W x D) 3.8 x 12.2 x17.2" / 97 x 311 x 438 mm
Weight 9.9 lbs / 4.5 kg
1 Equivalent Input Noise
Eect no. Eect
EDIT
Parameter 1
TAP/SELECT
Parameter 2
TAP/SELECT
LED
1 CATHEDRAL Reverb time Brilliance o/on
2 CONCERT Reverb time Brilliance o/on
3 CLUB Reverb time Brilliance o/on
4 CHAMBER Reverb time Brilliance o/on
5 GOLD PLATE Reverb time Brilliance o/on
6 GATED REV Reverb time Brilliance o/on
7 REVERSE Reverb time Brilliance o/on
8 AMBIENCE Room size Brilliance o/on
9 DELAY No. of repetitions
Time interval
TAP
ashing
(BPM tempo)
10 CHORUS Intensity
Tempo
TAP
ashing
(tempo)
11 FLANGER Intensity
Tempo
TAP
ashing
(tempo)
12 PHASER Intensity
Tempo
TAP
ashing
(tempo)
13 ROTARY Intensity Tempo o/on
14 PITCH SHIFT Semi-tone steps (+/-12) Detune o/on
15 DELAY+REV Delay vs. reverb ratio
Time interval
TAP
ashing
(BPM tempo)
16 CHORUS+REV Chorus vs. reverb ratio Reverb time o/on
FireWire, Mac and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
Mackie is a registered trademark of LOUD Technologies Inc.
