Alto S16 [14/23] Engaging this switch allows you to combine the 2 track output with the main mix in other words feeds the 2 track in signals into main l r output
![Alto S16 [14/23] Engaging this switch allows you to combine the 2 track output with the main mix in other words feeds the 2 track in signals into main l r output](/views2/1001010/page14/bge.png)
13
This control is used to adjust the level of the ALT output, and the adjustable range is from - to +15dB. This is another
way to offer you an extra independent stereo submix with its own level adjustment knob.
-. ALT 3-4
30
This LED indicates when the Power is on in your S-16.
-. POWER
31
Engaging this switch allows you to combine the ALT 3-4 output with the MAIN MIX, and feeds ALT 3 - 4 signals
into MAIN L / R output.
-. ALT 3-4 TO MAIN MIX
33
Engaging this switch allows you to combine the 2 TRACK Output with the MAIN MIX, in other words, feeds
the 2 TRACK IN signals into MAIN L / R output.
-. 2 TK TO MAIN MIX
34
-. PHONES / CONTROL ROOM
35
36
-. CONTROL ROOM SOURCE
You can choose to monitor any combination of MAIN MIX, ALT 3-4 and 2 TK IN via these MATRIX switches. The
ALT 3-4 is the additional stereo mix bus; 2 TK IN is the stereo signal coming in from the TAPE IN RCA jacks.
These stereo signals will be delivered to the PHONES / CONTROL ROOM and METERS display via engaging
these switches. If no switches engaged, there will be no signal at these outputs.
Note: When the channel's SOLO switch was engaged, then, the SOLO signal will replace other signals, and also
be sent to the CONTROL ROOM, PHONES and METERS.
-. PHANTOM
32
This LED indicates when the Phantom Power is switched on.
This Control sets the amount of signal sent to the Control Room and headphone.
