14
39 40
This switch is used to turn the Main Power ON and OFF.
-. POWER
38
4.17 REAR PANEL
POWER PHANTOM
AC INPUT
RATED POWER CONSUMPTION: 35W
EUROPE
210-240V 50Hz
Fuse:T250mAL
ON
OFF
Apparaten skall anslutas
till jordat uttag nar den
ansluts till ett natverk
Use only with a 250V fuse
Use only with a 250V fuse
Use only with a 250V fuse
37
38
2
These 1/4" sockets are unbalanced outputs. They
are capable of delivering +22dBu into the load.
Level to the ALT OUTPUT is adjusted by ALT 3-4
rotary knob on the front panel.
-. ALT OUTPUT
40
USA / Canada
100-120V 60Hz
Fuse:T500mAL
UK / Aust
240V 50Hz
Fuse:T250mAL
ALT OUTPUTMAIN OUTPUT
RIGHT(4) LEFT(3)
LEFTRIGHT
MAIN OUTPUT (BALANCED)MIX
LEFTRIGHT
OUTPUT
LEVEL
MAIN
MIC
+4dBu
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
REPLACE WITH THE SAME TYPE FUSE AND RATING
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
WARNING: SHOCK HAZARD
AVIS: RISQUE DE CHOC ELECTRIQUE
- DO NOT OPEN
- NE PAS OUVRIR
SERIAL
MODEL
12
3
12
3
-. MAIN OUTPUT LEVEL
41
When depress the switch, the output level from MAIN MIX OUTPUT will be reduced 30dB.
41
37
-. AC INLET & FUSE HOLDER
how the Voltage for your S-16 is configured before attempting to
connect your S-16 to the Main AC.
-. PHANTOM
2
This switch will apply +48 Volt Phantom Power only to the 8 XLR
microphone inputs. Never connect microphones when the Phantom
Power is on already.
-. MAIN MIX OUTPUT
39
This stereo output is supplied both with XLR
and 1/4" jack socket and it is controlled by the
Main Mix Level on the front panel. It will send
the audio signal to an amplifier. The output level
can be varied from - to +10dB.
Use it to connect your S-16 to the Main AC with the supplied AC
cord. Please check the Voltage available in your Country and
