Alto S16 [6/23] Features
![Alto S16 [6/23] Features](/views2/1001010/page6/bg6.png)
5
2. FEATURES
specific features:
. Ultra-low noise 16-channel 2+2-bus mixing console
8 MIC input channels with gold-plated XLRs and phone connectors
4 stereo input channels with balanced TRS jacks
2 stereo AUX returns for additional functionality
Ultra-low noise discrete MIC preamps with +48V Phantom power
Independent main mix, control room and headphone outputs
Peak LEDs on each channel
Low noise, high headroom
Balanced inputs and main outputs
PRE and POST fader AUX routing for external effects and monitoring
2-Track inputs assignable to Main Mix, Phones/Control Room outputs
+4dBu/-10dBV on each stereo channel
Mute/Alt 3-4, Solo function on each channel
Inserts on MIC channel
12-segment bar-graph meters for optimum reading of the output signal
High quality faders and sealed potentiometer
.
.
.
.
.
.
.
.
.
.
. Switchable low-cut filter on each mono channel
.
.
.
.
.
The S-16 16-Channel Mixing Console is designed for the professional application, and presents with the following
