SPECIFICATIONS
MODEL DS 70
DS 90
DS 90 X
ENGINE
Type 4-stroke, forced air cooled
Number of
cylinders
Single horizontal cylinder
Displacement 69.36 cm³ (4.2 in³) 89.53 cm³ (5.5 in³)
Starting
Electric/kick start
Type
For the summer season, use
XPS
SYNTHETIC BLEND OIL (SUMMER
GRADE) (P/N 293 600 121)
.
For the winter season, use
XPS SYNTHETIC
OIL (WINTER GRADE) (P/N 293 600
112)
.Refer to
OIL VISCOSITY CHART
Engine oil
Capacity
Oilchangewithfilter:
1.1 L (1.2 qt (U.S. liq.))
TRANSMISSION
Transmission
Continuously Variable Transmission (CVT)
GEARBOX
Type 3 positions: Forward, Neutral and Reverse
Type
XPS CHAINCASE OIL (P/N 415 129 500)
or an equivalent 75W90 chaincase oil
Gearbox oil
Capacity 165 ml (6 U.S. oz)
FUEL SYSTEM
Make KEHIN with manual choke
Carburetor
Type PTE
Idle speed 1700 ± 100 RPM
Type Unleaded gasoline
Inside
North
America
87 ((R + M)/2) or higher
Fuel
Octane
Outside
North
America
92 RON
Fuel tank
Capacity 6 L (1.6 U.S. gal.)
110
