MAINTENANCE SCHEDULE
MAINTENANCE SCHEDULE
WEEKLY
MONTHLY
ONCEAYEAROREVERY100HOURS
EVERY 2 YEARS OR 200 HOURS
A: Adjust
C: Clean
I: Inspect
L: Lubricate
R: Replace
TO BE PERFORMED BY
PART/TASK LEGEND
FUEL SYSTEM
Fuel lines and
connections
IDealer
Fuel filter R Dealer
Throttle cable/housing I, A L
Dealer/
Customer
Carburetor I, A, C
(4)
Dealer
Idle speed I Dealer
(4) Inspect, clean and adjust every
6months.
ELECTRICAL SYSTEM
Spark plug R Dealer
Battery I
Dealer/
Customer
—
DRIVE SYSTEM
Drive chain and
Sprockets
I
(5)
Dealer
(5) More often under severe use such
as dusty area, sand, snow, wet or
muddy conditions.
WHEELS/TIRES
Wheel bearings I Customer
Wheel bolts I Customer
—
TRANSMISSION (CVT)
Drive belt I Dealer
Drive and driven pulleys I, C, L Dealer
CVT air inlet/outlet ducts I, C Customer
—
_______________
81
