CONTROLS/INSTRUMENTS/EQUIPMENT
vmo2009-004-005_c
1. Engine start button
Choke Lever
This device features a variable position
lever used to ease starting a cold en-
gine.
The OFF position is used when the en-
gine is warm.
vmo2009-004-005_d
OFF POSITION
The full choke position is used when
theengineiscold.
vmo2009-004-006_a
FULL CHOKE POSITION
The other positions between OFF and
FULL will be used depending on the
engine temperature.
7) IndicatorLamps
The indicator lamps are located near
the middle of the handlebar.
vmo2008-008-019_a
TYPICAL
1. Neutral (N)
2. Reverse (R)
3. Ignition switch
Neutral Lamp (GREEN)
When lit, it indicates t
he
transmission is in neutral
position.
