Falmec Iris Gardenia ANG (600) S [19/96] Electrical connections

INSTALLATION

(Section reserved for qualified installers of the range hood)

The distance between the hob and the lowest part of the rangehood is normally

at least 65 cm (see figure C1). This distance is measuresd in the lowest part of

the rangehood not operating at safety voltage. Based on this detail provided by

European Standards, the distance may be reduced in some models as specified

in the general catalogue. If the instructions for installation for the gas hob speci-

fy a greater distance, this has to be taken into account.

In the outside exhaust version, the diameter of the fume discharge duct must

be no smaller than the range hood connection.

In the horizontal sections, the duct must slope slightly (around 10%) upwards,

so as to better convey the air outside of the room.

Avoid using angled pipes, make sure that the pipes are at least of the mini-

mum length.

Comply with the current regulations on air discharge into the atmosphere.

If a boiler, stove, fireplace, etc. that uses gas or other fuels is being used at

the same time, make sure the room where the fumes are extracted is well

ventilated, in compliance with the current regulations.

Mounting instruction: see section “O” of the booklet.

ELECTRICAL CONNECTIONS

(Section reserved for qualified installers)

WARNING!

Before doing any work inside the range hood, disconnect the appliance from

the mains power supply.

Check that the wires inside the range hood are not disconnected or cut; if this

is the case, contact your nearest service centre. The electrical connections

must be performed by qualified personnel.

The connections must be performed in compliance with the legal standards in

force. Check that the relief valve and the electrical system are able to support

the load of the appliance (see the technical specifications in point B).

Some types of appliance are supplied with a cable without plug; in this case,

“standardised” plugs must be used, keeping in mind that:

- the yellow-green wire must be used for the earth,

- the blue wire must be used for the neutral,

- the brown wire must be used for the phase; the cable must not come into

contact with hot parts (over 70°C).

- fit a plug that is suitable for the load to the power cable, and connect it to a

suitable power outlet.

For appliances that come supplied with cable and plug please ensure they are

plugged into a circuit suitable for this appliance.

Please refer to a qualifed person. (See technical specifications in point B).

The manufacturer declines all liability if the safety standards are not ob-

served.
