- Ensure that all regulations concerning the discharge of exhaust air have been

fulfilled before you use the appliance.

Before performing any cleaning or maintenance operations, disconnect the ap-

pliance by unplugging it or using the main switch. The manufacturer disclaims

all liability for any damage that may be directly or indirectly caused to people,

things and animals due to the failure to follow all the instructions provided in

this booklet and above all the warnings relating to the installation, operation

and maintenance of the appliance.

WARRANTY

The new equipment is covered by warranty. The warranty conditions are pro-

vided by the distributor.

The manufacturer is not liable for any inaccuracies in this booklet resulting

from printing or transcription errors. The manufacturer reserves the right to

modify its products as it considers necessary or in the interests of the user,

without compromising their essential safety and operating characteristics.

ASSEMBLY INSTRUCTIONS FOR

WALL-MOUNTED RUSTIC HOOD

Step 1

- Rest the support batten (A-Fig. 1) against the wall at a height above the hob

determined by the sum of the values X+Y+265 mm.

- Use a spirit level to make sure it is perfectly horizontal and make 2 marks at

the ends of the batten where the 2 holes are to be drilled.

- Drill the holes, insert the two ø 8mm screw anchors and fasten the batten

using the relevant screws.

Step 2

- Hook the hood onto the support batten (Fig. 2).

Step 3

- Adjust the alignment of the hood using the screws on the brackets (Fig. 3).

The upper screw (B) is used to adjust the distance from the wall, and the lower

screw (C) the vertical sliding

Step 4

- In order to prevent the hood from unhooking owing to pressure from under-

neath, fasten it to the wall with a screw anchor and relevant screw inserted in

the appropriate hole (Fig. 4).

ASSEMBLY INSTRUCTIONS FOR

CORNER HOODS WITHOUT BAR

Step 1

- Undo the rear metric screw (A) and remove the motor from the bottom of

the hood (fig. 1).

- Check the horizontal alignment with a spirit level and mark the 4 holes to be drilled.

- Drill the holes, insert 2 x 8mm dia. screw anchors and fix the hood in the desired
