Falmec Iris Gardenia ANG (600) S [27/96] Mounting the range hood without motor chamber

position, using 2 screws B fixed in the two slots in the top back panel (Fig. 5).

- Fit the safety screws C in the bottom back panels (Fig. 5).

Step 2

- After having fixed the hood, connect the flexible hose to the fume outlet hole

and to the circular pipe fitting of the motor chamber.

- Replace the motor at the bottom of the hood and secure it with the rear

metric screw (A) (fig. 2).

MOUNTING THE RANGE HOOD

WITHOUT MOTOR CHAMBER

1) Measure the distance (L) from the bottom of the range hood to the centre of

the mounting holes (Fig. 7).

2) Measure the distance (M) between the two mounting holes.

3) Line up the centre of the cooktop with the centre of the range hood. Is: L+650

mm.

4) The height of the holes to be drilled above the cooktop is calculated by adding

(L) to (H), where (H) is defined by point C-1.

5) Drill the holes for the Fischer screw anchors (the diameter of the holes depen-

ds on the type of screw anchor).

6) Before hanging and securing the range hood, remove:

- the steel grilles for range hoods with tangential motors

- the entire build-in assembly, if fitted, by unscrewing the screws that secure

it to the bottom.

7) To avoid hood unhooking due to underneath pressure, fix it to the wall with

a screw anchor and related screw, by using the appropriate holes at the back

of the hood or the cope flasks.

8) Hang the range hood.

9) Check, through the hole at the bottom, that the range hood is properly ancho-

red to the Fischer hooks.

10) Adjust the height of the range hood using the screws on the Fischer hooks.

11) Fit the steel grilles or the build-in assembly.

12) Mounting instruction for chimney (fig. 8):

- Fasten bracket (A) to the wall, at the correct distance;

- Fasten the upper part of the extension to bracket (A).
