BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 32
…………
Limit,0dB,–3dB,–6dB,–9dB,–12dBand–15dB.
17.USB
TheDX0.5maybecontrolledandprogrammedusingaWindows‐basedPC.Gotowww.MartinAudio.com/Softwaretodownload
thefreeapplicationanddriver.HereyouwillalsofindpresetsforotherMartinAudioproductranges
SimplyconnectaUSBcablefromtheDX0.5tothePCinordertocontrolallpa
rametersoftheprocessorviatheDX0.5Application.
FactoryReset
ItispossibletoresettheDX0.5LoudspeakerManagementSystemtoitsfactorysettings.Pleasekeepinmindthatthiserasesall
settings,includinganypasswordsandpresetsthatmayhave beenset.Besuretopowerdownanyamplifiersand/orpowered
speakersbeforeresettingtheDX0.5.
SimplypressandholdtheEnte
r[10],ESC[11]andUtility[12]buttonswhenpoweringupuntiltheLCD
Display[6]shows:
Please Wait....
Memory Reset
Thenyoumaytakeyourfingersoffthebuttons.YouwillknowitworkedwhenthesixoutputMuteLEDs[15]illuminateafterthe
DX0.5isfullypoweredup.
Thedefaultpasswordissixzeroes:000000
Utilities
Asmentionedearlier,therearethreemainutilitymenustochoosefrom:
SystemUtilities
PresetUtilities
SecurityUtilities
Withineachutilitymenu,anarrayofsub‐menusareavailable.Wewillgothrougheachutility,eachsubmenu,howtogetthere,
howtoeditandchangesettingsand whateac
hControlandbuttondoesineachsituation.
Whennavigatingmenus,thecurrentsettingforanyparameterwillbeindicatedwithanasterisk[*]makingiteasytogetback
whereyoustarted.
PresstheUtilityButton[12]toopentheUtilityMenu.
UsetheNav/Edit1Control[7]tonavigatebetweenthethreeutilitymenus:SystemUtilities,PresetUtilitiesandSecurityUtilities
.
PresstheESCbutton[11]toreturntothemainscreen.
PresstheEnterButton[10]toenterandedittheselectedUtilitiesmenu.Thisishowwereachthesub‐menusoftheUtilities.
SystemUtilities
TurntheNav/Edit1ControluntilSystemUtilitiesispresentedandpresstheEnterButton[10]toreachtheSystemUtilitiessub‐
menusaslistedbelow:
SystemSetup
DelayUnits
Rampsonchanges
SoftwareVersion
Lookingateachofthesesub‐m enusindividually;‐
1. TheNav/Edit1Control[7]isus
edtonavigatebetweenthefourSystemUtilities.
2. TheESCbutton[11]isusedtoreturntotheSystemUtilitiesmenu.
