BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 8
…………
2‐waypassivefull‐rangesystems
X8
TheX8isanultra‐compactpassivetwo‐waysystemfeaturingan8”(200mm)/2”(50mm)voicecoilLFdriveranda1”(25m m)HF
drivermountedona90°x50°hornwhichcanbeeasilyrotatedforhorizontalorverticalorientation.It'svery smallsizegivesno
indicationofitshighou
tputcapability.
Asastand‐aloneloudspeaker,ithasamultitudeofprofessionalapplications—fromdistributedsoundreinforcement,HoWand
AVeventstofront‐fill/infillanduseasamicrostagemonitor.ComplementedbyaBlacklineXsubwoofer,itistheideal,simple‐
to‐usesystemforportableapplicationsandinstallations which call fo
ranunobtrusivesystemthat can deliver pristinesound
overshortandmediumthrowdistances.
The X8 is constructed from birch/poplar plywood and fitted with a screw‐free steel grille, M8 inserts for a wall bracket and
eyebolt suspension, plus a pole‐mount socket. The X8 may be used with or with
out a system controller. For demanding
applications,MartinAudiorecommendsaDX0.5systemcontrollerconfiguredtoperformEQandlimiterfunctions.The DX0.5
mayalsobeusedtoconfiguresystemsforadditionalsub‐basscabinets–e.g.X8+X115orX210
