BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 38
…………
PresstheESCbutton[11]toexittheEQeditingmode.
Outputs1‐6:
EngagingEditonOutput(s)1‐6allowsyoutoeditthefollowing:
Name
Source
Polarity
Gain
EQBypass
7‐BandEQ
Delay
HighPassFilter
LowPassFilter
Limiter
VUMeter
1. TheNav/Edit1Control[7]isusedtonavi
gatebetweenName,Source,Polarity,Gain,EQBypass,7‐BandEQ,Delay,High
PassFilter,LowPassFilter,Limiterandthe VUMeter.
2. TheESCbutton[11]isusedtodisengageEditingandreturntothepreviousmenu.
PresstheEnterButton[10]toenterName.Anarrow–>willappearnexttoNameindicatingthatitisreadytobeedited.
Theaforementionedarrow–>willappearnexttowhateversettingisreadytobeedited:Name,Source,Polarity,Gain,EQBypass,
7‐BandEQ,Delay,HighPassFilter,Lo
wPassFilter,LimiterandtheVUMeter.
Name
Hereiswherethenameoftheselectedoutput(s) maybechanged.TheNav/Edit1 Control[7]movesthecursorleft and right
whiletheEdit2[8]andEdit3[9]Controlschangethetext.
Press the Enter button [10] to accept the newname andreturn tothe Edit menu. Pressingthe ESC but
ton leavesthe name
unchangedandreturnsyoutotheoutputeditmenu.
Source
Therearethreeinputsourcestochoosebetween:
InA=InputA
InB=InputB
InA+InB=AmonosumofInputA+InputB
Ifyouarerunningastereosystem,chooseeitherInputAorInputB.Ifthesystemismono(orhasamonocomp
onentsuchasa
subwooferorasingleloudspeakermountedinavenue’slobby,forexample),selectthe InputA+InputBchoice.
UsetheEdit2[8]orEdit3[9]Controltochangebetweenthesethreeoptions.
PresstheESCbutton[11]toexitinputsourceeditingmode.
Polarity
Polarityinversionisoftenhelpfulinimprovingphasealignmentthroughouttheloudspeakersystem,whetherusedseparatelyor
withasmallamountofdelay.Forexample,ifyouhaveissueswithasubwooferperformance,invertthepolaritytoseeifthesub
levelgetshigherorlower.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenPolarity = Normal[default]andPolarity = Invert[180˚].
PresstheESCbutton[11]toexitpolarityeditmode.
Gain
