BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 33
…………
3. TheEnterButton[10]isusedtoenterandeditthechosenSystemUtility.
PresstheEnterButton[10]toenterSystemSetup.
SystemSetup
SystemSetupiswheretheprocessorisconfiguredforyourparticularloudspeakersystem.Itconfigureschannelnames,input
routingtooutputsandprovidesstartingpointsforcrossoversetups.
The five options are listed below. Here, turn the Edit2 [8] or Edit3 [9] Control to scroll between the different System Setup
choices.
2x
Stereo+Sub[default]
Twofull‐rangeloudspeakerpairsandapairof[monobydefault]subwoofers
2x2Way+Sub
Twobi‐ampfull‐rangeloudspeakersandapairof[monobydefault]subwoofers
2x3Way
Twotri‐ampfull‐rangeloudspeakers
3xStereo
Threefull‐rangeloudspeakerpairs
1x6Way
Mono6‐way
Onceyo
uhavedecidedon asystem,presstheEnter Button [10]twice:once to selectand again toconfirm. Theoutputswill
automaticallymuteonceupdatedandtheprocessorreturnstotheSystemSetupsplashscreen.
YoumayconfiguretheDX0.5forotherscenariosbyadjustingtheavailableparameters.Ifyo
uarecreatingacustomsetup,choose
thesetupthatmostcloselyresemblesyoursystem,theneditfromthere.
PresstheESCbutton[11]toreturntotheSystemUtilitymenuwithoutmakinganychanges.
DelayUnits
Thisiswheretochooseunitsusedwhenadjustingtheinputandoutputdelayvalues.Youwillbepresentedwiththreeoptions
here:
Unit:Time(ms)
Unit:Distance(m)[default]
Unit:Distance(feet)
TurntheEdit2[8]orEdit3[9]Controltoscrollbetweenthesethreechoices.PresstheEnterButton[10]onceaunitofdelayha
s
beendecided.TheprocessorwillreturntotheDelayUnitssplashscreen.OrpresstheESCbutton[11]toreturntotheSystem
Utilitymenuwithoutmakinganychanges.
Rampsonchanges
Whenengaged,suddenvolumechangesmaybeavoidedwhenchangingparametervalues,pa rticularlywhenusingaWindows ‐
basedPCtocontroltheunit.Disengagethisfeatureforliveapplicationssinceinstantresponsetochangeisdesired.
TurntheEdit2[8]orEdit3[9]Controltoscrollbetween Ramps : On and Ramps : Off [default].Ifchanging,press
theEnterButton[10]onlyoncehere.TheprocessorwillreturntotheRampsonchangessplashscreen.OrpresstheESCbutton
[11]toreturntotheSystemUtilitymenuwithoutmakinganychanges.
SoftwareVersion
Nothingmaybeeditedonthispage.PresstheEnterButton[10]toviewwhatversionofsoftwareisinstalledinthisDX0.5.Press
theEnter[10]orESC[11]ButtontoreturntotheSoftwareVersionsplashscreen.
