BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 39
…………
In most cases you may need to adjust the output levels differently to properly balance the system components for ideal
performance.
UsetheEdit2[8]orEdit3[9]Controltochangethegainby±0.1dBperclick.TurningtheseControlsclockwiseincreasesgain,
whileturningthemanti‐clockwisedecreasesgain.Thegainran
gesfrom–12.0dBto+6.0dB.
PresstheESCbutton[11]toexitgaineditingmode.
EQBypass
EQBypassflattensthe7‐BandEQontheoutputsoyoumayhearexactlyhowitisaffectingthesystem.BytogglingtheEQBypass
onandoff,youmayquicklycompare thesoundwithandwithoutEQ.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenBypass = Off[default]andBypass = On.
PresstheESCbutton[11]toacceptthenewEQBypassmodeandexittheEQBypasseditingmode.
7‐BandEQ
OutputEQisusedprimarilyforadjustingtheresponseofaparticularloudspeakerortransducer.Additionally,outputEQmaybe
usedtocorrectroomanomaliesinmulti‐roomsetups.
UsetheNav/Edit1[7]Controltochangethefrequency.TurningthisControlclockwiseincreasesthefrequency,whileturningit
anti‐clockwisedecreasesthef
requency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
UsetheEdit2[8]Controltochangethebandwidthby±0.05perclick.TurningthisControlclockwiseincreasesthebandwidth,
whileturningitanticlockwise decreasesthebandwidth.TheEQbandmaybeconfiguredashighorlowshelfbyturningitallthe
wayanti‐clock
wise.
ThesearetheEQchoicesfromthefurthestanticlockwiseoptiontothefurthestclockwiseoption:
–12HighShelving
–6HighShelving
–12LowShelving
–6LowShelving
0.05–3.00[Parametric]
TochangetheEQbetweenshelvingandparametric,thegainmustfirstbesetto0.0dB.
UsetheEdit3[9
]Controltochangethegainby±0.5dBperclick.TurningthisControlclockwiseincreasesthegain,whileturning
itanti‐clockwisedecreasesthegain.Thegainrangesfrom–15.0dBto+15.0dB.
PresstheESCbutton[11]toexittheEQeditin
gmode.
Delay
Settingup output delayson the DX0.5 is useful for time and phase aligning transducers in bi‐ and tri‐amplified loudspeakers
systems,aligningsubwooferstofull‐rangeloudspeakers,aligningdelaysystemstomainsonstage,andmore.
Asstatedonpage14,Delaymaybepresentedinoneofthree ways:
Time(ms)
,or
Distance(m)[default],or
Distance(feet)
UsetheEdit2Control[8]tochangethe delayby:
±1.000msperclick,or
±0.340mperclick,or
±1.115feetperclick
UsetheEdit3Control[9]tochangethe delayby:
