![MARTIN Audioline X12 [55/64] Specifications](/views2/2013667/page55/bg37.png)
BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 54
…………
Specifications
X8
TYPE
Ultra-compact, passive two-way system
FREQUENCY RESPONSE (5) 70Hz – 20kHz ±3dB, -10dB @ 50Hz
DRIVER
LF: 8” (200mm)/2” (50mm) voice coil, ferrite motor system
HF: 1” (25mm) exit/1” (38mm) voice coil, polyimide dome compression driver
RATED POWER (2)
200W AES, 800W peak
RECOMMENDED AMPLIFIER
MA2.8Q, MA2.0
SENSITIVITY (8)
92dB
MAXIMUM SPL (9)
115dB continuous, 121dB peak
NOMINAL IMPEDANCE
8 ohms
DISPERSION (-6dB)
90° H x 50° V (user-rotatable)
CROSSOVER 2.9kHz passive
ENCLOSURE
Multi-angle birch/poplar ply
FINISH Black textured paint
PROTECTIVE GRILLE
Black perforated steel with scrim cloth backing
CONNECTORS
2 x NL4 type
PIN CONNECTIONS (INPUT
1+/1-
PIN CONNECTIONS (LINK)
1+/- to 1+/-
FITTINGS
13 x M8, 6 x M6 inserts, pole-mount socket, 1 x pocket handle
DIMENSIONS
(W) 257mm x (H) 422mm x (D) 243mm
(W) 10.1ins x (H) 16.6ins x (D) 9.6ins
WEIGHT
8kg (17.6lbs)
ACCESSORIES Wall bracket, eyebolts
X10
TYPE
Compact, passive two-way system
FREQUENCY RESPONSE (5)
65Hz-20kHz ± 3dB, -10dB @ 55Hz
DRIVERS
LF: 10” (250mm)/2.5” (63.5mm) voice coil ferrite motor system
HF: 1” (25mm) exit/1.4” (35mm) voice coil, polyimide dome compression driver
RATED POWER (2)
250W AES, 1000W peak
RECOMMENDED AMPLIFIER
MA2.0
SENSITIVITY (8)
94dB
MAXIMUM SPL (9)
118dB continuous, 124dB peak
NOMINAL IMPEDANCE 8 ohms
DISPERSION (-6dB)
90° H x 50° V (user-rotatable)
CROSSOVER 2.4kHz passive
ENCLOSURE
Multi-angle birch/poplar ply
FINISH
Black textured paint
PROTECTIVE GRILLE
Black perforated steel with scrim cloth backing
CONNECTORS
2 x NL4 type
PIN CONNECTIONS (INPUT
1+/1-
PIN CONNECTIONS (LINK)
1+/- to 1+/-
FITTINGS 19 x M8 inserts, pole-mount socket, 1 x bar handle
DIMENSIONS
(W) 324mm x (H) 522mm x (D) 289mm
(W) 12.8ins x (H) 20.6ins x (D) 11.4ins
WEIGHT
14kg (30.9lbs)
ACCESSORIES
Wall bracket, eyebolts
