BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 57
…………
X210
TYPE
Slimline, direct radiating subwoofer
FREQUENCY RESPONSE (5)
50Hz-150Hz ± 3dB, -10dB @ 42Hz
DRIVER 2 x 10” (250mm)/2” (50mm) voice coil, long excursion, ferrite magnet
RATED POWER (2)
500W AES, 2000W peak
RECOMMENDED AMPLIFIER
MA2.0, MA5.0Q
SENSITIVITY (8)
103dB
MAXIMUM SPL (9)
127dB continuous, 133dB peak (half space)
NOMINAL IMPEDANCE
4 ohms
DISPERSION (-6dB)
Omnidirectional
CROSSOVER
80-120Hz active
ENCLOSURE
Birch/poplar ply
FINISH Black textured paint
PROTECTIVE GRILLE
Black perforated steel
CONNECTORS 2 x NL4 type
PIN CONNECTIONS (INPUT
1+/1-
PIN CONNECTIONS (LINK)
1+/- to 1+/-
FITTINGS
16 x M10 inserts, pole-mount socket, 2 x bar handles
DIMENSIONS
(W) 720mm x (H) 295mm x (D) 465mm
(W) 28.3ins x (H) 11.6ins x (D) 18.3ins
WEIGHT
20kg (44.1lbs)
Notes
(1)Measuredon‐axisinhalf(2pi)spaceat2metres,thenreferredto1metre.
(2)AESStandardANSIS4.26‐1984.
(3)Measuredinhalf(2pi)space at2metreswith1wattinput,usingbandlimitedpinknoise,thenreferredto1metre.
(4)Measuredinhalf(2pi)space at2metresusingbandli
mitedpinknoise,thenreferredto1metre.
(5)Measuredon‐axisinopen(4pi)spaceat2metres,thenreferredto1metre.
(6)Measuredinopen(4pi)spaceat2metreswith1wattinput,usingbandlimitedpinknoise,thenreferredto1metre.
(7)Measuredinopen(4pi)spac
eat2metresusingbandlimitedpinknoise,thenreferredto1metre.
(8)Measuredinopen(4pi)spaceat2metreswith2.83vinput,usingbandlimitedpinknoise,thenreferredto1metre.
(9)Calculatedat1metre.
(10)Measuredinhalf(2pi)spac
eat2metreswith2.83Vinput,usingbandlimitedpinknoise,thenreferredto1metre.
