English | 19
pany for assistance. Contact with electric lines can lead
to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age or may cause an electric shock.
u Do not touch grinding and cutting discs until they have
cooled down. The discs can become very hot while work-
ing.
u Release the On/Off switch and set it to the off position
when the power supply is interrupted, e. g., in case of
a power failure or when the mains plug is pulled. This
prevents uncontrolled restarting.
u Secure the workpiece. A workpiece clamped with
clamping devices or in a vice is held more secure than by
hand.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for cutting, roughing and brush-
ing metal and stone materials without the use of water.
A separate protective guard for cutting must be used when
cutting with bonded abrasives.
Sufficient dust extraction must be provided when cutting
stone.
With approved abrasive tools, the power tool can be used for
sanding with sanding discs.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Spindle lock button
(2)
On/off switch
(3)
Auxiliary handle (insulated gripping surface)
(4)
Combination wrench for grinding spindle M14
a)
(5)
Combination wrench for grinding spindle M10
a)
(6)
Grinding spindle
(7)
Protective guard for grinding
(8)
Locking screw for protective guard
(9)
Mounting flange with O‑ring
(10)
Grinding disc
a)
(11)
Clamping nut
(12)
Quick-clamping nut
a)
(13)
Carbide grinding head
a)
(14)
Protective guard for cutting
a)
(15)
Cutting disc
a)
(16)
Hand guard
a)
(17)
Rubber sanding pad
a)
(18)
Abrasive disc
a)
(19)
Round nut
a)
(20)
Cup brush
a)
(21)
Handle (insulated gripping surface)
(22)
Speed preselection thumbwheel (GWS 750 S)
a)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Angle Grinder GWS 700 GWS 700 GWS 710 GWS 710 GWS 750 GWS 750 S
Article number
3 601 C94 0.. 3 601 C94 0.. 3 601 C94 0.. 3 601 C94 0.. 3601C940..
3601C942..
3 601 C94 1..
Rated power input W 700 700 710 750 750 750
Power output W 355 355 355 380 380 380
Rated speed min
-1
11,000 11,000 11,000 11,000 11,000 11,000
Speed adjustment
range
min
-1
– – – – – 2800–11,000
Max. grinding disc
diameter
mm 115 125 115 125 115 115
Grinding spindle
thread
M 14 M 14 M 14 M 14 M 14 M 14
Bosch Power Tools 1 609 92A 6KK | (07.06.2021)
