FERM GTM1005 [10/96] Assembly
![FERM GTM1005 [10/96] Assembly](/views2/2015737/page10/bga.png)
10
EN
3. ASSEMBLY
Before any work on the power tool,
remove the battery.
Warning! Do not use the grass trimmer
without the protection guard.
The machine must be charged before
first use
Inserting the battery into the machine
(Fig. C)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
• Hold the machine firmly with one hand.
•
Insert the battery (1) into the base of the machine.
• Push the battery further forward until it clicks
into place.
Removing the battery from the machine
(Fig. C)
• Hold the machine firmly with one hand.
• Push down the battery unlock button (2)
located on the rear side of the battery (1) with
the other hand.
• Keep pushing the unlock button (2) down
and slide the battery backwards out of the
machine, like shown in Fig. C.
Mounting the Protection guard (Fig. B1)
• Fit the protection guard (10) onto the trimmer
head housing.
• Secure the guard using the screw (11) delivered.
Mounting the guardrail (Fig. B2)
• Squeeze the ends of the guardrail (12) together
and slide into the holes of the trimmer head
housing
• The guardrail can be set in different protection
distances. To adjust the rail, simply press or
pull the rail.
Mounting the front handle (Fig. D1)
• Place the handle (8) on the holder mounted on
the upper shaft.
• Fit the bolt in the hexagon hole and mount the
knob (9) onto the bolt.
Adjusting the front handle (Fig. D2)
• Unscrew the knob (9) slightly and press or pull
the front handle (8) in to desirable position.
This can either be down or upwards and
rotatable around upper shaft.
When using the machine sideways
always use the sidewheel
Mounting of the side wheel (Fig. E)
• Slide side wheel (13) over the side wheel
holder (14).
Mounting the wire spool (Fig. F1)
Before replacing the spool clean the
machine from any dirt.
• Place the spring (17) into the spool housing
(18). Make sure the wider side of the spring is
placed on the trimmer head.
• Place the spool reel (16) over the spring (17).
Make sure the wires are passed through the
holes inside the housing (18). (Fig. F2)
• Cover the spool reel with the spool cover (15)
and fasten it by turning the cover tightly.
Replacing the spool (Fig. F1)
• Remove the spool cover (15)
• Take out the spool reel (16) but leave the spring
(17) inside.
• Take the new spool reel (GTA1002) and place
it over the spring (17). Make sure the wires are
passed through the holes inside the housing
(18). (Fig. F2)
• Cover the new spool reel with the spool cover
(15) and fasten it by turning the cover tightly.
4. OPERATION
Using the tap and go system (Fig. G)
• When the wire is too short, switch the machine
on and press the tip of the spool reel (19) on
the ground (make sure this is done on a hard
surface).
• This will release the wire in order to get longer.
• The wire will be cut on the correct length
automatically by the blade mounted in the
protection guard (10).
