First FA-5553-1 [2/14] English

INSTRUCTION MANUAL

Thank you for purchasing this high quality Fan. Our fans have been carefully designed and constructed

to meet the highest standards of performance, quality and safety. Please read the instructions carefully to

ensure satisfactory and trouble free use.

YOUR FAN FEATURES

• 3 Speed Control

• Oscillation over an Angle of 80°

• Protective Grille

• Adjustable for height

• Use the appliance only on the voltage specified on its rating plate (220-240V/50Hz).

• Unplug from outlet when not in use and before cleaning.

• Do not pull the connection cord over sharp edges and never jam it.

• Do not pull the plug out of the socket by pulling the connection cord.

• Do not use outdoors.

• Do not use an extension cord, unless the cord has been checked and tested by your electrical authority

or a qualified technician.

• Close supervision is necessary when any appliance is used by or near children.

• Always use your appliance on a suitabel level and dry platform.

• Avoid using an appliance where it can fall or be pushed into water. Never reach for an appliance after it

• Do not spray pesticide towards. It may make the resin and coating bad or broken.

• Do not use the fan in such place where the curtain may be drawn in.

• Do not use before assembly.

where there is acid alkali oil, etc.

• The babies, patients and old men should not be blown directly for a long time.

and dry and if the fan blades rotates freely.

1. ASSEMBLY THE STAND (picture 2)

• Fix the cross bars (18).

• Put the standing shaft (17) on the cross bars.

• Screw the standing shaft on the cross bars with four screws.

2. THE WHOLE ASSEMBLY (picture 3)

• Loosen the fixing screw (16) and pull the electroplated shaft (15) to the height needed and then fix it firmly.

• Link the fan main body and the adjustable electroplated shaft (15) together by the fixing screw (14) and then

fix them.

3. REAR NET ASSEMBLY (picture 4)

• Screw the net fastening screw (6) out in anti-clockwise direction.

5. FRONT NET ASSEMBLY (picture 6)

• The safety grille has five clips that you now need to lift to complete the assembly.

• Align the top locking clip to the top of the rear safety grille. Lock the side clips in place and align the

bottom hole for the security nut and bolt. Undo the security lock and bolt and thread the aligned holes in

the security tools before doing up the bolt with a pair of pliers or a similar tool.

OPERATING INSTRUCTIONS

• This fan has three types of speed control.

Strong 3

Middle 2 Piano switches of the wind adjusting

Weak 1

You can help protect the environment! Please remember to respect the local regulations: hand in the non-

working electrical equipments to an appropriate waste disposal center.

3

ENGLISH

2

ENGLISH

1. Front guard

2. Guard screw

3. Decoration cover

4. Blade Fastening screw

5. Fan Blade

12. Oscillate control knob
