TRANSLATION OF

THE ORIGINAL INSTRUCTIONS

BELT SANDER

59G392

CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL

CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.

DETAILED SAFETY REGULATIONS

• Use the belt sander for sanding only.

• Do not use the belt sander when it is held in ﬁxed position, by

moving processed material.

• Inhalation of dust, such as lead based, metal or of certain wood

species (e.g. oak), is dangerous to your health. Therefore it is

necessary to always work with device for dust extraction.

• Do not use the sander for materials that contain asbestos.

• Wear protective half mask and anti-splinter goggles when

sanding.

• Use of earmuﬀs is recommended.

• Fix processed material to prevent it from slipping. You can ﬁx the

material e.g. using a vice.

• Use sanding belts of recommended size only.

• Before starting to replace sanding belt, disconnect the sander

from power supply by removing power cord plug from mains

socket.

• During operation, move the sander when holding it ﬁrmly with

both hands.

• Always follow instructions contained in general and detailed

safety regulations for using hand-held power tools.

CAUTION! This device is designed to operate indoors.

The design is assumed to be safe, protection measures and

additional safety systems are used, nevertheless there is always a

small risk of operational injuries.

CONSTRUCTION AND USE

Belt sander is a power tool driven by a single-phase commutator

motor. The sander does not require earth lead (insulation class II).

Belt sander is designed for surface sanding of wood products,

polishing wood surfaces with lacquer coating, ﬁne polishing of

lacquered metal surfaces, removal of rust or specks of lacquer before

applying new lacquer, ﬁnishing of concrete surfaces etc. Range of

use covers repair and building works, woodworking and any work

from the scope of individual, amateur activities (tinkering).

Use the power tool according to the manufacturer’s instructions

only.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the

drawing pages of this manual.

1. Additional handle

2. Carbon brush cover

3. Dust extraction outlet

4. Driving belt cover

5. Wheel for sanding belt adjustment

6. Sanding belt

7. Main handle

8. Switch

9. Switch lock button

10. Guiding roller

11. Sanding belt tension lever

12. Locking lever for additional handle

13. Cover of sanding belt

* Diﬀerences may appear between the product and drawing.

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY/SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Dust bag - 1 pce

2. Endless belt - 1 pce

PREPARATION FOR OPERATION

DUST EXTRACTION

Equipment of belt sander includes dust bag that helps to maintain

the processed surface clean. The dust bag can be installed on the

dust outlet (3) (g. A).

Empty the dust bag regularly, it will ensure eﬃcient operation of the

sander. It is recommended to empty the dust bag when it is half full.

• Slide the dust bag onto the dust outlet (3) to install it.

• Pull the dust bag gently to check if it is well ﬁxed.

• Deinstallation of the dust bag is similar to installation, only the

sequence of actions is reversed.

INSTALLATION OF SANDING BELT

Prior to sanding belt installation ensure the switch is in the o

position and that power cord is disconnected from mains network.

• Move the sanding belt tension lever (11) to the end in the

direction shown by the arrow (g. B).

• Put sanding belt on rollers (g. C).

• Move the sanding belt tension lever (11) to its original position

(g. D).

Ensure the direction of the arrow located on the sanding paper

back surface matches direction of the arrow located on the belt

sander body.

ADDITIONAL HANDLE

Additional handle (1) makes it easier to hold the sander safely and

guide it when sanding.

It is possible to set the additional handle to a position comfortable

for the work being performed.

• Pull away the locking lever for additional handle (13).

• Set the additional handle (1) to desired position (g. J).

• Press in the locking lever for additional handle (13).

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

Before connecting the belt sander to a power supply network,

always check that power supply voltage matches rated voltage

shown on the rating plate that is xed to the power tool, and that

switch is in the o position.

During operation hold the sander rmly with both hands. Switch

on the belt sander only when it is lifted above the material that

you plan to process.

Switching on – press the switch button (8) and hold in this position.

Switching o – release pressure on the switch button (8).

Locking the switch (continuous operation)

Switching on:

• Press the switch button (8) and hold in this position.

• Press the switch lock button (9) (g. E).

• Release pressure on the switch (8).
